Brainboxes 8 Port RS232 USB to Serial Adapter

Brainboxes 8 Port RS232 USB to Serial Adapter

Model US-279EAN 5052179932403

38 specifications
  • ConnectivityWired
  • Weight878 g
  • ColourBlack
  • Host interfaceUSB Type-B
  • InternalNo
  • Data transfer rate (max)0.48 Gbit/s
See all specifications

Overview

Connectivity
Wired
Weight
878 g
Colour
Black
Host interface
USB Type-B
Internal
No
Data transfer rate (max)
0.48 Gbit/s
Brand
Brainboxes
Model
US-279
Part number
US-279
EAN / UPC
5052179932403, 641254230432, 837324002133, 8373240021336 +1 more
Also known as
Brainboxes 8 Port RS232 USB to Serial Adapter

Specifications

38 specifications in 9 groups

Ports & interfaces

Host interfaceUSB Type-B
Output interfaceSerial
Host interface genderFemale
USB 2.0 ports quantity1
Serial ports quantity8
Serial interface typeRS-232

Design

InternalNo
Product colourBlack
CertificationMicrosoft Certified Gold Partner, CE, WEEE, RoHS, TAA

Features

Data transfer rate (max)0.48 Gbit/s
Baud rate921.6 Kbit/s
Data bits7, 8
Flow control supportYes
Parity bitNo, Odd, Even, Mark, Space
Flow Control typeRTS/CTS, DTR/DSR, XON/XOFF
Plug and PlayYes
Export Control Classification Number (ECCN)4A994

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpris
Mac operating systems supportedYes
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2008, Windows Server 2008 x64

Technical details

Compliance certificatesCE, UKCA, Federal Communications Commission (FCC)
International Protection (IP) codeIP30

Weight & dimensions

Width215 mm
Depth123 mm
Height56 mm
Weight878 g

Packaging data

Power supply includedYes
Package width300 mm
Package depth135 mm
Package height80 mm
Package weight1.2 kg

Logistics data

Harmonized System (HS) code84718

Other features

Connectivity technologyWired
Compatible operating systemsWindows XP, Server 2003, Vista, Server 2008, Windows 7
Mac compatibilityNo
Package dimensions (WxDxH)230 x 250 x 70 mm
Power requirements600mA / 5V
