3M WX36 data projector 3000 ANSI lumens WXGA (1280x800) White

3M WX36 data projector 3000 ANSI lumens WXGA (1280x800) White

Model WX36EAN 051125633802

67 specifications
  • ConnectivityWired
  • Noise37 dB
  • Weight3.6 kg
  • ColourWhite
  • Projector brightness3000 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Connectivity
Wired
Noise
37 dB
Weight
3.6 kg
Colour
White
Projector brightness
3000 ANSI lumens
Light source type
Lamp
Brand
3M
Model
WX36
Part number
WX36
EAN / UPC
051125633802, 078923677203
Also known as
3M WX36 data projector 3000 ANSI lumens WXGA (1280x800) White

Specifications

67 specifications in 14 groups

Projector

Projector brightness3000 ANSI lumens
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)2000:1
Screen size compatibility762 - 7620 mm (30 - 300")
Number of colours16.78 million colours
Projector brightness (economic mode)2200 ANSI lumens
Horizontal scan range31.5 - 106 kHz
Vertical scan range56 - 120 Hz
Keystone correction, vertical-30 - 30°
Matrix size1.5 cm (0.59")
Matrix type3-panel (p-Si TFT active)

Light source

Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)6000 h
Lamp typeUHB
Lamp power210 W
Lamp power (economic mode)140 W

Lens system

FocusAuto
Focal length range19 - 23 mm
Zoom capabilityYes
Zoom typeManual
Zoom ratio1.2:1
Magnification4x

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Full HDYes
HD-ReadyYes
3DNo
Supported graphics resolutions1600 x 1200 (UXGA)
Supported video modes1080i, 480i, 480p, 576i, 720p

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity1
Component video (YPbPr/YCbCr) in1
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity0
Audio (L/R) in1
Audio (L/R) out1
Microphone inYes
Serial interface typeRS-232
PC Audio inYes
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Features

Noise level37 dB
Noise level (economic mode)30 dB
CertificationUL, cUL, FCC-B, EN60950-1, CE.

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power16 W

Design

Product colourWhite

Power

Power consumption (typical)330 W
Power consumption (standby)1 W
AC input voltage110 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Weight3.6 kg

Packaging content

Remote control includedYes

Other features

Aspect ratio16:10
Connectivity technologyWired
Dimensions (WxDxH)317 x 288 x 98 mm
Lens focal rangeF 1.67 - 1.91
Maximum analog resolution1600 x 1200 pixels
Maximum operating altitude1829 m
RS-232 ports1
