Product comparison · 2 data projectors

3M WX36 data projector 3000 ANSI lumens WXGA (1280x800) White vs 3M X26 data projector 3200 ANSI lumens LCD XGA (1024x768) White

Add a product
  • 62specifications compared
  • 22differ
  • 40identical
  • 26known for one product only

Key differences

  • Projector brightness
    • 3000 ANSI lumens
    • 3200 ANSI lumens
  • Projector native resolution
    • WXGA (1280x800)
    • XGA (1024x768)
  • Contrast ratio (typical)
    • 2000:1
    • 500:1
  • Keystone correction, vertical
    • -30 - 30°
    • ±30°
  • Matrix size
    • 1.5 cm (0.59")
    • 1.6 cm (0.63")
  • Service life of light source (economic mode)
    • 6000 h
    • 4000 h
  • Lamp power
    • 210 W
    • 200 W
  • Focus
    • Auto
    • Manual

Side by side

Differences highlightedShow differences only
88 specifications
A

3M

WX36 data projector 3000 ANSI lumens WXGA (1280x800) White

Model WX36

View product
B

3M

X26 data projector 3200 ANSI lumens LCD XGA (1024x768) White

Model X26

View product
Projector5 differ
Projector brightnessDiffers3000 ANSI lumens3200 ANSI lumens
Projection technologyKnown for oneLCD
Projector native resolutionDiffersWXGA (1280x800)XGA (1024x768)
Contrast ratio (typical)Differs2000:1500:1
Screen size compatibility762 - 7620 mm (30 - 300")762 - 7620 mm (30 - 300")
Projection distanceKnown for one1.8 - 2.2 m
Number of colours16.78 million colours16.78 million colours
Projector brightness (economic mode)2200 ANSI lumens2200 ANSI lumens
Horizontal scan range31.5 - 106 kHz31.5 - 106 kHz
Vertical scan range56 - 120 Hz56 - 120 Hz
Keystone correction, verticalDiffers-30 - 30°±30°
Matrix sizeDiffers1.5 cm (0.59")1.6 cm (0.63")
Matrix type3-panel (p-Si TFT active)3-panel (p-Si TFT active)
Light source2 differ
Light source typeLampLamp
Service life of light source3000 h3000 h
Service life of light source (economic mode)Differs6000 h4000 h
Lamp typeUHBUHB
Lamp powerDiffers210 W200 W
Lamp power (economic mode)140 W140 W
Lamps quantityKnown for one1 lamp(s)
Lens system1 differ
FocusDiffersAutoManual
Focal length range19 - 23 mm19 - 23 mm
Zoom capabilityYesYes
Zoom typeManualManual
Zoom ratio1.2:11.2:1
Optical zoomKnown for one1.2x
Throw ratioKnown for one1.5 - 1.8:1
Magnification4x4x
Video2 differ
Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAMNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Full HDDiffersYesNo
HD-ReadyYesYes
3DNoNo
Supported graphics resolutionsDiffers1600 x 1200 (UXGA)1024 x 768 (XGA), 1600 x 1200 (UXGA)
Supported video modes1080i, 480i, 480p, 576i, 720p1080i, 480i, 480p, 576i, 720p
Ports & interfaces3 differ
VGA (D-Sub) ports quantityDiffers23
HDMI ports quantityDiffers10
Component video (YPbPr/YCbCr) in11
Composite video in11
DVI portNoNo
S-Video inputs quantity11
USB 2.0 ports quantityDiffers01
Headphone outputsKnown for one1
Microphone inYesYes
Serial interface typeRS-232RS-232
USB connector typeKnown for oneUSB Type-B
AC (power) inYesYes
Audio (L/R) inKnown for one1
Audio (L/R) outKnown for one1
PC Audio inKnown for oneYes
Network2 differ
Ethernet LANDiffersYesNo
Ethernet LAN (RJ-45) portsDiffers10
Wi-FiNoNo
Storageidentical
Card reader integratedKnown for oneNo
Features1 differ
Noise level37 dB37 dB
Noise level (economic mode)30 dB30 dB
CertificationDiffersUL, cUL, FCC-B, EN60950-1, CE.UL, cUL, FCC Part 15 Subpart B, Class B, EN60950-1, CE
Multimedia1 differ
Built-in speaker(s)YesYes
Number of built-in speakers11
RMS rated powerDiffers16 W1 W
TV tuner integratedKnown for oneNo
Designidentical
Product colourWhiteWhite
Power2 differ
Power consumption (typical)Differs330 W290 W
Power consumption (standby)1 W1 W
AC input voltageDiffers110 - 240 V100 - 240 V
AC input frequency50 - 60 Hz50 - 60 Hz
Auto power offKnown for oneYes
Supplier featuresidentical
Battery typeKnown for oneAA
Operational conditionsidentical
Operating temperature (T-T)5 - 35 °C5 - 35 °C
Storage temperature (T-T)-20 - 60 °C-20 - 60 °C
Operating altitudeKnown for one0 - 1829 m
Weight & dimensions1 differ
WeightDiffers3.6 kg2.2 kg
WidthKnown for one306 mm
DepthKnown for one221 mm
HeightKnown for one77 mm
Packaging contentidentical
Remote control includedYesYes
Batteries includedKnown for oneYes
Cables includedKnown for oneVGA
Other features2 differ
Aspect ratioDiffers16:104:3, 14:9, 16:9
Audio inputKnown for one2
Audio outputKnown for one2
Connectivity technologyWiredWired
Dimensions (WxDxH)Differs317 x 288 x 98 mm306 x 221 x 77 mm
Lens systemKnown for oneF = 1.67 - 1.91
Maximum analog resolution1600 x 1200 pixels1600 x 1200 pixels
RS-232 ports11
Digital keystone correctionKnown for oneYes
Lens focal rangeKnown for oneF 1.67 - 1.91
Maximum operating altitudeKnown for one1829 m

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
