IDATA HDMI-109VW
Model IDATA HDMI-109VWEAN 8058956620409
23 specifications
- ColourBlack
- Number of displays supported9
- HDMI input ports quantity1
- Power consumption (typical)4 W
- Operating temperature (T-T)-20 - 60 °C
- Width265 mm
Overview
- Colour
- Black
- Number of displays supported
- 9
- HDMI input ports quantity
- 1
- Power consumption (typical)
- 4 W
- Operating temperature (T-T)
- -20 - 60 °C
- Width
- 265 mm
- Brand
- Techly
- Category
- Video Wall Processor
- Model
- IDATA HDMI-109VW
- Part number
- IDATA HDMI-109VW
- EAN / UPC
- 8058956620409
- Also known as
- Techly IDATA HDMI-109VW video wall processor Black
Specifications
23 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Control type | Buttons |
Features
| Specification | Value |
|---|---|
| Number of displays supported | 9 |
| Scaled resolutions | 4096 x 2160 |
| Maximum refresh rate | 60 Hz |
| HDCP | Yes |
| HDCP version | 1.4 |
| Maximum resolution | 4096 x 2160 pixels |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 9 |
| HDMI version | 1.4 |
| 3.5 mm connector | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 4 W |
| Input voltage | 5 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 265 mm |
| Depth | 105 mm |
| Height | 25 mm |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Mounting kit | Yes |
