VLVW1X4 video wall processor Black
11 W
Model VLVW1X4EAN 5704174472650
26 specifications
- Weight450 g
- ColourBlack
- Supported video modes1080p
- HDMI input ports quantity1
- Power consumption (max)11 W
- Operating temperature (T-T)-5 - 55 °C
Overview
- Weight
- 450 g
- Colour
- Black
- Supported video modes
- 1080p
- HDMI input ports quantity
- 1
- Power consumption (max)
- 11 W
- Operating temperature (T-T)
- -5 - 55 °C
- Brand
- Vivolink
- Category
- Video Wall Processor
- Model
- VLVW1X4
- Part number
- VLVW1X4
- EAN / UPC
- 5704174472650
- Also known as
- Vivolink VLVW1X4 video wall processor Black 11 W
Specifications
26 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Built-in display | No |
| Control type | Buttons |
Features
| Specification | Value |
|---|---|
| Supported video modes | 1080p |
| Number of displays supported | 4 |
| Scaled resolutions | 1920 x 1080 |
| Maximum refresh rate | 60 Hz |
| HDCP | Yes |
| HDCP version | 2.0 |
| Audio formats supported | PCM |
| Maximum resolution | 3840 x 2160 pixels |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 4 |
| HDMI version | 2.0b |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 11 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Power supply location | External |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 110 mm |
| Height | 18 mm |
| Weight | 450 g |
| Package weight | 550 g |
