Studio X70 All-In-One Video Bar with TC10 Controller Kit No Power Cord GSA/TAA
Model Studio X70 All-In-One Video Bar with TC10 Controller Kit No Power Cord GSA/TAAPart no. 8L538AAEAN 017229198128
44 specifications
- TypeVideo collaboration bar
- Weight3.2 kg
- ColourBlack
- HD type4K Ultra HD
- Built-in speaker(s)Yes
- HDMI ports quantity3
Overview
- Type
- Video collaboration bar
- Weight
- 3.2 kg
- Colour
- Black
- HD type
- 4K Ultra HD
- Built-in speaker(s)
- Yes
- HDMI ports quantity
- 3
- Brand
- HP Poly
- Category
- Video Conferencing System
- Model
- Studio X70 All-In-One Video Bar with TC10 Controller Kit No Power Cord GSA/TAA
- Part number
- 8L538AA
- EAN / UPC
- 017229198128, 197497837643
- Also known as
- HP Poly Studio X70 All-In-One Video Bar with TC10 Controller Kit No Power Cord GSA/TAA
Specifications
44 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Product type | Video collaboration bar |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Product colour | Black |
Video
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum video resolution | 3840 x 2160 pixels |
| Supported video modes | 1080p, 720p, 2160p |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1400 x 1050 (SXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160 |
| Video formats supported | H.264, H.265, AVC |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 20 W |
| Voice codecs | G.719, G.728, G.722, G.165, G.722.1, G.729B |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Line-in | Yes |
| Line-out | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Wi-Fi | Yes |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 20 MP |
| Camera type | Dual camera |
| Second camera resolution | 20 MP |
| Zoom capability | Yes |
| Digital zoom | 7.3x |
| Horizontal field of view | 120° |
Technical details
| Specification | Value |
|---|---|
| General Product Safety Regulation (GPSR) URL | https://kaas.hpcloud.hp.com/pdf-public/pdf_11006260_en-US-1.pdf |
Features
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross weight | 357 kg |
| UNSPSC-code | 45111902 |
Operational conditions
| Specification | Value |
|---|---|
| Heat dissipation | 65 BTU/h |
| Operating relative humidity (H-H) | 15 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 840.2 mm |
| Depth | 135.4 mm |
| Height | 117.3 mm |
| Weight | 3.2 kg |
