STB-5500 TV set-top box IPTV Full HD Black
Model STB-5500EAN 719192919723
45 specifications
- Weight635 g
- ColourBlack
- Signal sourceIPTV
- Audio formats supportedAAC, EAC3, MP3, PCM
- Ethernet LANYes
- USB 2.0 ports quantity2
Overview
- Weight
- 635 g
- Colour
- Black
- Signal source
- IPTV
- Audio formats supported
- AAC, EAC3, MP3, PCM
- Ethernet LAN
- Yes
- USB 2.0 ports quantity
- 2
- Brand
- LG
- Category
- TV Set-Top Box
- Model
- STB-5500
- Part number
- STB-5500
- EAN / UPC
- 719192919723, 8806087168037, 8806087168167
- Also known as
- LG STB-5500 TV set-top box IPTV Full HD Black
Specifications
45 specifications in 13 groups
Video
| Specification | Value |
|---|---|
| Signal source | IPTV |
| HD type | Full HD |
| Personal Video Recorder (PVR) included | No |
| Analog signal format system | NTSC |
| Video resolutions | 3840 x 2160 pixels |
| Supported video modes | 1080p |
| Aspect ratio | 16:9 |
File formats
| Specification | Value |
|---|---|
| Audio formats supported | AAC, EAC3, MP3, PCM |
| Image formats supported | JPG |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Miracast | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| S-Video outputs quantity | 0 |
| Composite video out | 0 |
| SCART ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Component video (YPbPr/YCbCr) out | 0 |
| Digital audio coaxial out | 0 |
| Digital audio optical out | 1 |
| RS-232 interface | Yes |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Tuner type | Analog & digital |
| Number of tuners | 1 tuner(s) |
| Audio decoders | Dolby Digital |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Power consumption (typical) | 14.1 W |
| Power consumption (standby) | 0.5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 208.3 mm |
| Depth | 30.5 mm |
| Height | 170.2 mm |
| Weight | 635 g |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 361 x 206 x 137 mm |
| Package weight | 1.77 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | UL, FCC, cUL |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Sustainability certificates | ENERGY STAR |
