0070-24155 surveillance monitor
139.7 cm (55") 3840 x 2160 pixels
Model 0070-24155EAN 5715063081211
42 specifications
- Display139.7 cm (55")
- Resolution3840 x 2160 pixels
- Energy classF
- Weight35.3 kg
- Housing materialMetal
- Analog signal format systemPAL
Overview
- Display
- 139.7 cm (55")
- Resolution
- 3840 x 2160 pixels
- Energy class
- F
- Weight
- 35.3 kg
- Housing material
- Metal
- Analog signal format system
- PAL
- Brand
- Ernitec
- Category
- Surveillance Monitor
- Model
- 0070-24155
- Part number
- 0070-24155
- EAN / UPC
- 5715063081211
- Also known as
- Ernitec 0070-24155 surveillance monitor 139.7 cm (55") 3840 x 2160 pixels
Specifications
42 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Housing material | Metal |
| Certification | EMC Class A |
Display
| Specification | Value |
|---|---|
| Display diagonal | 139.7 cm (55") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| Display aspect ratio | 16:9 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.315 x 0.315 mm |
| Contrast ratio (typical) | 4000:1 |
| Response time | 5 ms |
| Native refresh rate | 60 Hz |
Performance
| Specification | Value |
|---|---|
| Analog signal format system | PAL |
| Built-in speaker(s) | Yes |
| Panel mounting interface | 400 x 200 mm |
| VESA mounting | Yes |
| Operating hours (hours/days) | 24/7 |
| On Screen Display (OSD) languages | English |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| DisplayPorts quantity | 1 |
| HDMI version | 2.0 |
| VGA (D-Sub) ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal |
| Power consumption (typical) | 120 W |
| Power consumption (standby) | 0.1 W |
| Power consumption (off) | 0.1 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| AC adapter output voltage | 100-240 V |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | F |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 85 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 35.3 kg |
| Height | 835 mm |
| Depth | 232 mm |
| Width | 1360 mm |
| Package width | 1360 mm |
| Package depth | 232 mm |
| Package height | 835 mm |
| Package weight | 40.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
