QX3202 surveillance monitor CCTV monitor
81.3 cm (32") 3840 x 2160 pixels
Model QX3202EAN 4710739598803
77 specifications
- Display81.3 cm (32")
- Resolution3840 x 2160 pixels
- Energy classG
- TypeCCTV monitor
- Weight10.2 kg
- ColourBlack
Overview
- Display
- 81.3 cm (32")
- Resolution
- 3840 x 2160 pixels
- Energy class
- G
- Type
- CCTV monitor
- Weight
- 10.2 kg
- Colour
- Black
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- QX3202
- Part numbers
- QX3202, QX322011E0000
- EAN / UPC
- 4710739598803
- Also known as
- AG Neovo QX3202 surveillance monitor CCTV monitor 81.3 cm (32") 3840 x 2160 pixels
Specifications
77 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Housing material | Metal |
| Mounting type | Ceiling/wall |
| Product colour | Black |
| IK code | IK08, IK10 |
Display
| Specification | Value |
|---|---|
| Display diagonal | 81.3 cm (32") |
| Display resolution | 3840 x 2160 pixels |
| Display type | LED |
| Panel type | VA |
| Display brightness | 350 cd/m² |
| Display aspect ratio | 16:9 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.182 x 0.182 mm |
| Contrast ratio (typical) | 3000:1 |
| Response time | 5 ms |
| Haze rate | 25% |
| Anti-glare screen | Yes |
| Surface hardness | 3H |
| Digital horizontal frequency | 30 - 160 kHz |
| Digital vertical frequency | 30 - 76 Hz |
| Glass thickness | 3.2 mm |
| Native refresh rate | 60 Hz |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 10 W |
| Picture-by-Picture (PbP) | Yes |
| Picture-in-Picture | Yes |
| Panel mounting interface | 200 x 200 mm |
| VESA mounting | Yes |
| Operating hours (hours/days) | 24/7 |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 4 |
| DisplayPort version | 1.2 |
| HDMI version | 2.0 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| Ethernet LAN | Yes |
| RJ-45 ports quantity | 1 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Audio output | 3.5 mm |
| RS-232 ports | 2 |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power supply type | External |
| Power consumption (typical) | 48 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 24 V |
| AC adapter output current | 5.5 A |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 48 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Low Voltage Directive (LVD), REACH, RoHS, BSMI, CCC, cUL, UL, Federal Communications Commission (FCC), KCC, PSE, RCM, UKCA, WEEE |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 10.2 kg |
| Height | 451.4 mm |
| Depth | 79.3 mm |
| Width | 756.5 mm |
| Bezel width (bottom) | 1.28 cm |
| Bezel width (side) | 1.28 cm |
| Bezel width (top) | 1.28 cm |
| Package width | 850 mm |
| Package depth | 145 mm |
| Package height | 530 mm |
| Package weight | 12.6 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | HDMI, AC |
| Remote control included | Yes |
| Quick start guide | Yes |
