FDF2312W-IP surveillance monitor
58.4 cm (23") 1920 x 1080 pixels
Model FDF2312W-IPEAN 690592057737
38 specifications
- Display58.4 cm (23")
- Resolution1920 x 1080 pixels
- Weight4.2 kg
- ColourBlack
- Mounting typeFreestanding
- Built-in speaker(s)Yes
Overview
- Display
- 58.4 cm (23")
- Resolution
- 1920 x 1080 pixels
- Weight
- 4.2 kg
- Colour
- Black
- Mounting type
- Freestanding
- Built-in speaker(s)
- Yes
- Brand
- EIZO
- Category
- Surveillance Monitor
- Model
- FDF2312W-IP
- Part number
- FDF2312W-IP
- EAN / UPC
- 690592057737, 4995047064701
- Also known as
- EIZO FDF2312W-IP surveillance monitor 58.4 cm (23") 1920 x 1080 pixels
Specifications
38 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Mounting type | Freestanding |
| Product colour | Black |
| Certification | CE, UKCA, CB, RCM, cTÜVus, FCC-A, CAN ICES-3 (A), TÜV/S, PSE, VCCI-A, RoHS, WEEE, China RoHS, CCC, BIS |
Display
| Specification | Value |
|---|---|
| Display diagonal | 58.4 cm (23") |
| Display resolution | 1920 x 1080 pixels |
| Display type | LCD |
| Panel type | IPS |
| Display brightness | 300 cd/m² |
| Display aspect ratio | 16:9 |
| Display viewable area (HxV) | 509.1 x 286.4 mm |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.265 x 0.265 mm |
| Contrast ratio (typical) | 1000:1 |
| Response time | 8 ms |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN | Yes |
| RJ-45 ports quantity | 1 |
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
| 3.5 mm (1/8-inch) out | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (max) | 49 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.2 kg |
| Height | 324.4 mm |
| Depth | 59.5 mm |
| Width | 547.2 mm |
| Width (with stand) | 547.2 mm |
| Depth (with stand) | 157 mm |
| Height (with stand) | 411.3 mm |
| Weight (with stand) | 6.6 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Quick start guide | Yes |
