24 inch LED Monitor
Model LM24-L200NPart no. 06923172540515EAN 6923172540515
65 specifications
- Display60.5 cm (23.8")
- Resolution1920 x 1080 pixels
- Energy classE
- TypeCCTV monitor
- Weight2.8 kg
- ColourBlack
Overview
- Display
- 60.5 cm (23.8")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Type
- CCTV monitor
- Weight
- 2.8 kg
- Colour
- Black
- Brand
- Dahua Technology
- Category
- Surveillance Monitor
- Model
- LM24-L200N
- Part numbers
- 06923172540515, DHI-LM24-L200N
- EAN / UPC
- 6923172540515, 6923172509031
- Also known as
- Dahua Technology 24 inch LED Monitor
Specifications
65 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Mounting type | Freestanding/Wall-mounted |
| Product colour | Black |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15° |
| Certification | CE ERP |
Display
| Specification | Value |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Display type | LED |
| Panel type | VA |
| Display brightness | 250 cd/m² |
| Backlight type | E-LED |
| Display aspect ratio | 16:9 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Contrast ratio (typical) | 3000:1 |
| Response time | 5 ms |
| NTSC coverage (typical) | 72% |
| Native refresh rate | 100 Hz |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Operating hours (hours/days) | 24/7 |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power supply type | External |
| Power consumption (max) | 18 W |
| Power consumption (typical) | 17.5 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Input current | 2 A |
| AC adapter output voltage | 12 V |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 17 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD) |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.8 kg |
| Height | 325.2 mm |
| Depth | 53.6 mm |
| Width | 540.4 mm |
| Width (with stand) | 540.4 mm |
| Depth (with stand) | 190 mm |
| Height (with stand) | 419.1 mm |
| Weight (with stand) | 3.3 kg |
| Bezel width (bottom) | 2.06 cm |
| Bezel width (side) | 2.6 mm |
| Bezel width (top) | 2.6 mm |
| Package width | 601 mm |
| Package depth | 145 mm |
| Package height | 400 mm |
| Package weight | 4 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | HDMI |
| Quantity | 1 |
