SC-24E surveillance monitor CCTV monitor
60.5 cm (23.8") 1920 x 1080 pixels
Model SC-24EEAN 4710739595543
49 specifications
- Display60.5 cm (23.8")
- Resolution1920 x 1080 pixels
- Energy classE
- TypeCCTV monitor
- Weight3.4 kg
- ColourBlack
Overview
- Display
- 60.5 cm (23.8")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Type
- CCTV monitor
- Weight
- 3.4 kg
- Colour
- Black
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- SC-24E
- Part number
- SC-24E
- EAN / UPC
- 4710739595543
- Also known as
- AG Neovo SC-24E surveillance monitor CCTV monitor 60.5 cm (23.8") 1920 x 1080 pixels
Specifications
49 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Mounting type | Freestanding |
| Product colour | Black |
| Certification | FCC, CE, CB, WEEE, RoHS, REACH,EAC, BSMI |
Display
| Specification | Value |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Display type | LCD |
| Display brightness | 250 cd/m² |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.275 x 0.275 mm |
| Horizontal scan range | 24 - 83 kHz |
| Vertical scan range | 50 - 75 Hz |
| Response time | 5 ms |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (typical) | 22 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| AC adapter output voltage | 100 - 240 V |
| Energy efficiency class (SDR) | E |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 55 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 93% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.4 kg |
| Height | 322.6 mm |
| Depth | 49.6 mm |
| Width | 540.6 mm |
| Package width | 620 mm |
| Package depth | 122 mm |
| Package height | 420 mm |
| Package weight | 5.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Quantity | 1 |
