SC-19E surveillance monitor CCTV monitor
47 cm (18.5") 1366 x 768 pixels
Model SC-19EEAN 4710739595529
49 specifications
- Display47 cm (18.5")
- Resolution1366 x 768 pixels
- Energy classE
- TypeCCTV monitor
- Weight2 kg
- ColourBlack
Overview
- Display
- 47 cm (18.5")
- Resolution
- 1366 x 768 pixels
- Energy class
- E
- Type
- CCTV monitor
- Weight
- 2 kg
- Colour
- Black
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- SC-19E
- Part number
- SC-19E
- EAN / UPC
- 4710739595529
- Also known as
- AG Neovo SC-19E surveillance monitor CCTV monitor 47 cm (18.5") 1366 x 768 pixels
Specifications
49 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Mounting type | Freestanding |
| Product colour | Black |
| Certification | FCC, CE, CB, WEEE, RoHS, REACH,EAC |
Display
| Specification | Value |
|---|---|
| Display diagonal | 47 cm (18.5") |
| Display resolution | 1366 x 768 pixels |
| Display type | LCD |
| Display brightness | 250 cd/m² |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.3 x 0.3 mm |
| Horizontal scan range | 24 - 83 kHz |
| Vertical scan range | 50 - 75 Hz |
| Contrast ratio (typical) | 20000000:1 |
| Response time | 3 ms |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (typical) | 16 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| AC adapter output voltage | 100 - 240 V |
| Energy efficiency class (SDR) | E |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 13 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 55 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 93% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2 kg |
| Height | 268.3 mm |
| Depth | 48.3 mm |
| Width | 441.9 mm |
| Package width | 492 mm |
| Package depth | 123 mm |
| Package height | 360 mm |
| Package weight | 3.6 kg |
Packaging content
| Specification | Value |
|---|---|
| Quantity | 1 |
