RX-55E CCTV monitor
138.7 cm (54.6") 1920 x 1080 pixels
Model RX-55EPart no. R55E0011E0000EAN 4710739595307
55 specifications
- Display138.7 cm (54.6")
- Resolution1920 x 1080 pixels
- Energy classG
- TypeCCTV monitor
- Weight37 kg
- ColourBlack
Overview
- Display
- 138.7 cm (54.6")
- Resolution
- 1920 x 1080 pixels
- Energy class
- G
- Type
- CCTV monitor
- Weight
- 37 kg
- Colour
- Black
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- RX-55E
- Part number
- R55E0011E0000
- EAN / UPC
- 4710739595307
- Also known as
- AG Neovo RX-55E CCTV monitor 138.7 cm (54.6") 1920 x 1080 pixels
Specifications
55 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Mounting type | Freestanding/Wall-mounted |
| Product colour | Black |
| LED indicators | Yes |
| Certification | FCC, LVD ,EAC, BSMI |
Display
| Specification | Value |
|---|---|
| Display diagonal | 138.7 cm (54.6") |
| Display resolution | 1920 x 1080 pixels |
| Display type | TFT |
| Display brightness | 700 cd/m² |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.63 x 0.63 mm |
| Horizontal scan range | 31 - 92 kHz |
| Vertical scan range | 48 - 85 Hz |
| Contrast ratio (typical) | 1300:1 |
| Response time | 5 ms |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 10 W |
| Panel mounting interface | 400 x 400 mm |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 2 |
| HDMI version | 1.4 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Composite video in | 1 |
| USB 2.0 ports quantity | 1 |
| Composite video out | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (typical) | 133 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 133 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS, WEEE |
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 37 kg |
| Height | 739.6 mm |
| Depth | 83 mm |
| Width | 1268.8 mm |
| Package width | 1475 mm |
| Package depth | 223 mm |
| Package height | 936 mm |
| Package weight | 43.7 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | No |
| Quantity | 1 |
