RX-24G surveillance monitor CCTV monitor
59.9 cm (23.6") 1920 x 1080 pixels
Model RX-24GEAN 4710739595901
54 specifications
- Display59.9 cm (23.6")
- Resolution1920 x 1080 pixels
- Energy classE
- TypeCCTV monitor
- Weight7.3 kg
- ColourBlack
Overview
- Display
- 59.9 cm (23.6")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Type
- CCTV monitor
- Weight
- 7.3 kg
- Colour
- Black
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- RX-24G
- Part numbers
- RX-24G, RX4G00A1E0100, RX4G0011E0100
- EAN / UPC
- 4710739595901, 190695002509, 4710739595918
- Also known as
- AG Neovo RX-24G surveillance monitor CCTV monitor 59.9 cm (23.6") 1920 x 1080 pixels
Specifications
54 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product type | CCTV monitor |
| Mounting type | Freestanding/Wall-mounted |
| Product colour | Black |
| LED indicators | Yes |
| Certification | CB, CE, FCC, BSMI ,RoHS, WEEE, REACH |
Display
| Specification | Value |
|---|---|
| Display diagonal | 59.9 cm (23.6") |
| Display resolution | 1920 x 1080 pixels |
| Display type | LCD |
| Display brightness | 300 cd/m² |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.272 x 0.272 mm |
| Horizontal scan range | 24 - 83 kHz |
| Vertical scan range | 50 - 75 Hz |
| Contrast ratio (typical) | 20000000:1 |
| Response time | 3 ms |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Composite video in | 2 |
| USB 2.0 ports quantity | 1 |
| Composite video out | 2 |
| 3.5 mm (1/8-inch) in | Yes |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power supply type | External |
| Power consumption (typical) | 25 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 20 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 7.3 kg |
| Height | 352.6 mm |
| Depth | 56.2 mm |
| Width | 562.4 mm |
| Package width | 672 mm |
| Package depth | 249 mm |
| Package height | 517 mm |
| Package weight | 11.2 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quantity | 1 |
