RX-2202 54.6 cm (21.5") 1920 x 1080 pixels
Model RX-2202Part no. RX222011E0000EAN 4710739598339
55 specifications
- Display54.6 cm (21.5")
- Resolution1920 x 1080 pixels
- Energy classE
- ColourBlack
- Mounting typeFreestanding/Wall-mounted
- Built-in speaker(s)Yes
Overview
- Display
- 54.6 cm (21.5")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Colour
- Black
- Mounting type
- Freestanding/Wall-mounted
- Built-in speaker(s)
- Yes
- Brand
- AG Neovo
- Category
- Surveillance Monitor
- Model
- RX-2202
- Part number
- RX222011E0000
- EAN / UPC
- 4710739598339
- Also known as
- AG Neovo RX-2202 54.6 cm (21.5") 1920 x 1080 pixels
Specifications
55 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Mounting type | Freestanding/Wall-mounted |
| Product colour | Black |
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 17° |
| IK code | IK10 |
Display
| Specification | Value |
|---|---|
| Display diagonal | 54.6 cm (21.5") |
| Display resolution | 1920 x 1080 pixels |
| Panel type | IPS |
| Display brightness | 250 cd/m² |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.248 x 0.248 mm |
| Contrast ratio (typical) | 20000000:1 |
| Response time | 5 ms |
| NTSC coverage (typical) | 72% |
| Surface hardness | 9H |
| Digital horizontal frequency | 24 - 83 kHz |
| Digital vertical frequency | 50 - 75 Hz |
| Glass thickness | 3 mm |
| Transmission rate | > 97% |
Performance
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Cable lock slot type | Kensington |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Audio output | Yes |
| RS-232 ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (max) | 25 W |
| Power consumption (typical) | 16 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | E |
| Energy efficiency scale | A to G |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Low Voltage Directive (LVD), Federal Communications Commission (FCC), BSMI, RoHS, WEEE, cUL, UL, RCM, KCC, EAC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 513.2 mm |
| Depth (with stand) | 155 mm |
| Height (with stand) | 368.5 mm |
| Weight (with stand) | 6.4 kg |
| Package width | 614 mm |
| Package depth | 204 mm |
| Package height | 477 mm |
| Package weight | 9 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
