00AE938 RAID controller PCI Express 3.0 12000 Gbit/s
Model 00AE938EAN 883436545990
25 specifications
- ProcessorLSI
- Memory2048 MB
- Weight116 g
- Supported storage drive interfacesSAS, Serial ATA
- RAID Level MigrationYes
- Operating temperature (T-T)5 - 40 °C
Overview
- Processor
- LSI
- Memory
- 2048 MB
- Weight
- 116 g
- Supported storage drive interfaces
- SAS, Serial ATA
- RAID Level Migration
- Yes
- Operating temperature (T-T)
- 5 - 40 °C
- Brand
- Lenovo
- Category
- RAID Controller
- Model
- 00AE938
- Part number
- 00AE938
- EAN / UPC
- 883436545990, 4053162528604, 4056572859085
- Also known as
- Lenovo 00AE938 RAID controller PCI Express 3.0 12000 Gbit/s
Specifications
25 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Supported storage drive interfaces | SAS, Serial ATA |
| Host interface | PCI Express |
| PCI Express slots version | 3.0 |
| External mini-SAS HD ports | 2 |
Performance
| Specification | Value |
|---|---|
| RAID Level Migration | Yes |
| RAID levels | 0, 1, 5, 10 |
| Data transfer rate | 12000 Gbit/s |
| Internal memory | 2048 MB |
| Internal memory type | DDR3 |
| Memory clock speed | 1866 MHz |
| Chipset | SAS3108 |
| Number of devices supported | 32 |
| S.M.A.R.T. support | Yes |
| Certification | UL cUL IEC60950 EMC FCC TUV CE VCCI BSMI C-tick KC |
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor family | LSI |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Microsoft Windows Server 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows Server 2016 Red Hat Enterprise Linux 6 Server Edition Red Hat Enterprise Linux 6 Server x64 Edition SUSE Enterprise Linux Server (SLES) 12 SUSE LINUX Enterprise Server 11 for AMD64/EM64T |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 93% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 68 mm |
| Depth | 170 mm |
| Height | 17 mm |
| Weight | 116 g |
Other features
| Specification | Value |
|---|---|
| PCI Card form factor | Half-height (low-profile) |
