FRITZ!Powerline 1260E WLAN Set
Model FRITZ!Powerline 1260E WLAN SetPart no. 20002795EAN 4023125027956
29 specifications
- Speed1200 Mbit/s
- Weight200 g
- ColourWhite
- AC input voltage230 V
- LED indicatorsLAN, Power
- Width67 mm
Overview
- Speed
- 1200 Mbit/s
- Weight
- 200 g
- Colour
- White
- AC input voltage
- 230 V
- LED indicators
- LAN, Power
- Width
- 67 mm
- Brand
- FRITZ!
- Category
- PowerLine Network Adapter
- Model
- FRITZ!Powerline 1260E WLAN Set
- Part number
- 20002795
- EAN / UPC
- 4023125027956
- Also known as
- Powerline FRITZ! 1260E WLAN Set 1200 Mbit/s Ethernet LAN Wi-Fi White
Specifications
29 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1200 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g |
| WLAN data transfer rates supported | 866 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i |
| Power plug | Type F |
| Built-in power socket | Yes |
| PowerLine standard | HomePlug AV2 |
| Security algorithms | 128-bit AES |
Power
| Specification | Value |
|---|---|
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
Design
| Specification | Value |
|---|---|
| LED indicators | LAN, Power |
| Product colour | White |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 67 mm |
| Depth | 32 mm |
| Height | 132 mm |
| Weight | 200 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 184 mm |
| Package depth | 132 mm |
| Package height | 110 mm |
| Package weight | 700 g |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
