TL-WPA7510KIT 1000 Mbit/s Ethernet LAN Wi-Fi White 2 pc(s)
Model TL-WPA7510KITPart no. TL-WPA7510 KITEAN 5704174217985
45 specifications
- Speed1000 Mbit/s
- ColourWhite
- Power consumption (standby)2.2 W
- Antenna typeInternal
- Windows operating systems supportedYes
- Operating temperature (T-T)0 - 40 °C
Overview
- Speed
- 1000 Mbit/s
- Colour
- White
- Power consumption (standby)
- 2.2 W
- Antenna type
- Internal
- Windows operating systems supported
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- TP-Link
- Category
- PowerLine Network Adapter
- Model
- TL-WPA7510KIT
- Part number
- TL-WPA7510 KIT
- EAN / UPC
- 5704174217985
- Also known as
- TP-Link TL-WPA7510KIT 1000 Mbit/s Ethernet LAN Wi-Fi White 2 pc(s)
Specifications
45 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rates supported | 300,433 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Built-in power socket | No |
| PowerLine standard | HomePlug AV2 |
| Modulation | OFDM |
| Security algorithms | 128-bit AES, WPA, WPA2, WPS |
| Maximum operating distance | 300 m |
| Encryption button | Yes |
| Quality of Service (QoS) support | Yes |
| Plug and Play | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 2.2 W |
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
Design
| Specification | Value |
|---|---|
| Antenna type | Internal |
| LED indicators | Yes |
| Product colour | White |
| Certification | FCC, CE |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 135.6 mm |
| Depth | 70.8 mm |
| Height | 49 mm |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 230 mm |
| Package depth | 190 mm |
| Package height | 100 mm |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 2 pc(s) |
| Manual | Yes |
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85171800 |
