Product comparison · 2 powerline network adapters

FRITZ!Powerline 1220 Set INT vs FRITZ!Powerline 1260E WLAN Set

22specifications compared
6differ
16identical
13known for one product only

Key differences

Ethernet LAN (RJ-45) ports
- FRITZ!Powerline 1220 Set INT:2
- FRITZ!Powerline 1260E WLAN Set:1
Wi-Fi
- FRITZ!Powerline 1220 Set INT:No
- FRITZ!Powerline 1260E WLAN Set:Yes
Width
- FRITZ!Powerline 1220 Set INT:59 mm
- FRITZ!Powerline 1260E WLAN Set:67 mm
Depth
- FRITZ!Powerline 1220 Set INT:41 mm
- FRITZ!Powerline 1260E WLAN Set:32 mm
Weight
- FRITZ!Powerline 1220 Set INT:220 g
- FRITZ!Powerline 1260E WLAN Set:200 g

Side by side

Differences highlightedShow differences only

Comparison of FRITZ!Powerline 1220 Set INT, FRITZ!Powerline 1260E WLAN Set
35 specifications	A FRITZ! FRITZ!Powerline 1220 Set INT View product	B FRITZ! FRITZ!Powerline 1260E WLAN Set View product
Performance2 differ
Maximum data transfer rate	1200 Mbit/s	1200 Mbit/s
Ethernet LAN	Yes	Yes
Ethernet LAN interface type	Gigabit Ethernet	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T	10BASE-T, 100BASE-T, 1000BASE-T
Ethernet LAN (RJ-45) portsDiffers	2	1
Wi-FiDiffers	No	Yes
Wi-Fi standardsKnown for one	Unknown — not stated by the source	802.11a, 802.11b, 802.11g
WLAN data transfer rates supportedKnown for one	Unknown — not stated by the source	866 Mbit/s
Networking standardsKnown for one	Unknown — not stated by the source	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i
Power plug	Type F	Type F
Built-in power socket	Yes	Yes
PowerLine standard	HomePlug AV2	HomePlug AV2
Security algorithms	128-bit AES	128-bit AES
Quality of Service (QoS) supportKnown for one	Yes	Unknown — not stated by the source
Poweridentical
AC input voltage	230 V	230 V
AC input frequency	50 Hz	50 Hz
Power consumption (typical)Known for one	3 W	Unknown — not stated by the source
Power consumption (standby)Known for one	1 W	Unknown — not stated by the source
Designidentical
LED indicators	LAN, Power	LAN, Power
Product colour	White	White
System requirements1 differ
Windows operating systems supportedDiffers	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 H	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home
Weight & dimensions3 differ
WidthDiffers	59 mm	67 mm
DepthDiffers	41 mm	32 mm
Height	132 mm	132 mm
WeightDiffers	220 g	200 g
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	184 mm
Package depthKnown for one	Unknown — not stated by the source	132 mm
Package heightKnown for one	Unknown — not stated by the source	110 mm
Package weightKnown for one	Unknown — not stated by the source	700 g
Package typeKnown for one	Box	Unknown — not stated by the source
Packaging contentidentical
Quick installation guide	Yes	Yes
Cables included	LAN (RJ-45)	LAN (RJ-45)
Quantity per packKnown for one	2 pc(s)	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	85171800	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
