APC Switched Rack PDU

APC Switched Rack PDU

Model Switched Rack PDUPart no. AP8653EAN 731304276982

37 specifications
  • Power7680 W
  • TypeSingle-phase
  • Weight8.23 kg
  • ColourBlack
  • AC outlets quantity24 AC outlet(s)
  • Cable length3 m
See all specifications

Overview

Power
7680 W
Type
Single-phase
Weight
8.23 kg
Colour
Black
AC outlets quantity
24 AC outlet(s)
Cable length
3 m
Brand
APC
Model
Switched Rack PDU
Part number
AP8653
EAN / UPC
731304276982
Also known as
APC Rack PDU 2G, Metered by Outlet with Switching, ZeroU, 32A, 230V, (21) C13 & (3) C19

Specifications

37 specifications in 10 groups

Design

PDU typesMetered, Metered-by-outlet, Switched
TypeSingle-phase
Rack capacity0U
MountingVertical
Product colourBlack

Ports & interfaces

AC outlets quantity24 AC outlet(s)
Power plugIEC309
AC outlet typesC13 coupler, C19 coupler

Features

Cable length3 m

Management features

MonitoringCurrent, Power, Voltage
Outlet controlLock-out, Recycle, Turn off, Turn on

Power

Nominal input voltage230 V
AC input frequency50 - 60 Hz
Maximum current32 A
Nominal output voltage230 V
Load capacity7680 VA
Maximum input current per phase32 A
Maximum total current draw per phase32 A
Maximum power7680 W
Power protection featuresOverload

Certificates

Compliance certificatesRoHS
CertificationEN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, VDE

Operational conditions

Operating temperature (T-T)-5 - 45 °C
Storage temperature (T-T)-25 - 65 °C
Operating relative humidity (H-H)5 - 95%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Weight & dimensions

Width56 mm
Depth51 mm
Height1829 mm
Weight8.23 kg

Packaging data

Package weight10.5 kg
Package width162 mm
Package depth118 mm
Package height2038 mm

Logistics data

Total carbon footprint (kg of CO2e)8595.81
