NetShelter Rack PDU, Metered, 0U, 5.0kW
200V and 208V 30A, (36) C13 and (6) C19 outlets
Model AP8841EAN 7313042770026
47 specifications
- TypeSingle-phase
- Weight6.84 kg
- ColourBlack
- PDU typesBasic
- AC outlets quantity42 AC outlet(s)
- Cable length2.9 m
Overview
- Type
- Single-phase
- Weight
- 6.84 kg
- Colour
- Black
- PDU types
- Basic
- AC outlets quantity
- 42 AC outlet(s)
- Cable length
- 2.9 m
- Brand
- APC
- Category
- Power Distribution Units (PDUs)
- Model
- AP8841
- Part number
- AP8841
- EAN / UPC
- 7313042770026, 151903011164, 191120031903, 601000713817 +9 more
- Also known as
- APC NetShelter Rack PDU, Metered, 0U, 5.0kW 200V and 208V 30A, (36) C13 and (6) C19 outlets
Specifications
47 specifications in 11 groups
Design
| Specification | Value |
|---|---|
| PDU types | Basic |
| Type | Single-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 42 AC outlet(s) |
| Power plug | NEMA L6-30P |
| AC outlet types | NEMA L6-30P |
| Input connection type | NEMA L6-30P |
| Output connections | 36x IEC 320 C13 6x IEC 320 C19 |
Features
| Specification | Value |
|---|---|
| Cable length | 2.9 m |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 200; 208 V |
| AC input frequency | 50-60 Hz |
| Maximum current | 30 A |
| Output voltage | 200 V; 208 V |
| Load capacity | 4992 VA |
| Maximum input current per phase | 30 A |
| Maximum total current draw per phase | 30 A |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, REACH, WEEE |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Certification | CSA C22.2 No. 60950,IEC 60950,METI Denan,UL 60950-1,VDE RoHS,REACH |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 60 °C |
| Storage temperature (T-T) | -25 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15240 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 56 mm |
| Depth | 44 mm |
| Height | 1791 mm |
| Weight | 6.84 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Serial |
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 6.47 kg |
| Package width | 107 mm |
| Package depth | 162 mm |
| Package height | 2000 mm |
Technical details
| Specification | Value |
|---|---|
| Halogen free | No |
| Packaging recycled materials | Recycled cardboard |
| Preferred mounting position | no preference |
| Removable battery | Yes |
| Packaging without single use plastic | No |
| Sustainable packaging | No |
| Take-back system | No |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | India |
| Customs product code (TARIC) | 8537109899 |
| Total carbon footprint (kg of CO2e) | 2676.8173692539 |
