PoE12-30W
Model PoE12-30WPart no. POE12-30WEAN 4718937621668
13 specifications
- Weight144 g
- Ethernet LAN data rates100,1000,2500 Mbit/s
- Power consumption (max)0.07 W
- Operating temperature (T-T)-10 - 45 °C
- Width140 mm
Overview
- Weight
- 144 g
- Ethernet LAN data rates
- 100,1000,2500 Mbit/s
- Power consumption (max)
- 0.07 W
- Operating temperature (T-T)
- -10 - 45 °C
- Width
- 140 mm
- Brand
- Zyxel
- Category
- PoE Adapter
- Model
- PoE12-30W
- Part numbers
- POE12-30W, POE12-30W-EU0101F, POE12-30W-GB0101F
- EAN / UPC
- 4718937621668, 760559127879, 4718937620227
- Also known as
- Zyxel PoE12-30W
Specifications
13 specifications in 4 groups
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 0.07 W |
| Total Power over Ethernet (PoE) budget | 30 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 45 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 45.5 mm |
| Height | 30 mm |
| Weight | 144 g |
