1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at)
30W Power Budget, Wall Mountable, Unmanaged Inline Power Over Ether
Model AF211C-POE-INJECTOREAN 065030905169
45 specifications
- Weight100 g
- ColourBlack
- Ethernet interface typeGigabit Ethernet
- Ethernet LAN (RJ-45) ports2
- AC adapter input voltage100 - 240 V
- Operating temperature (T-T)0 - 50 °C
Overview
- Weight
- 100 g
- Colour
- Black
- Ethernet interface type
- Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 2
- AC adapter input voltage
- 100 - 240 V
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- StarTech.com
- Category
- PoE Adapter
- Model
- AF211C-POE-INJECTOR
- Part number
- AF211C-POE-INJECTOR
- EAN / UPC
- 065030905169
- Also known as
- StarTech.com 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at), 30W Power Budget, Wall Mountable, Unmanaged Inline Power Over Ether
Specifications
45 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000 |
| Power over Ethernet (PoE) | Yes |
| Auto MDI/MDI-X | Yes |
| Cable types supported | Cat5, Cat5e, Cat6, Cat6a |
| Chipset | Monolithic Power Systems - MP3924 |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u |
| Web-based management | No |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Wall mountable | Yes |
| Maximum operating distance | 100 m |
| LED indicators | Power |
| Jumbo frames | 9000 |
| Jumbo frames support | Yes |
| Auto-negotiation | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
Power
| Specification | Value |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 54 V |
| Input current | 2.5 A |
| Output current | 3.3 A |
| Total Power over Ethernet (PoE) budget | 30 W |
| Power plug type | Type M |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, UL |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating temperature (T-T) | -10 - 70 °F |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 58 mm |
| Depth | 100 mm |
| Height | 33 mm |
| Weight | 100 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Power cord included | Yes |
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 212 mm |
| Package depth | 125 mm |
| Package height | 52 mm |
| Package weight | 424.5 g |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 524 mm |
| Master (outer) case length | 290 mm |
| Master (outer) case height | 464 mm |
| Products per master (outer) case | 40 pc(s) |
