PoE Splitter
Model TL-POE10RPart no. TL-POE10R V1EAN 5053313218254
27 specifications
- ColourWhite
- Ethernet interface typeGigabit Ethernet
- Ethernet LAN (RJ-45) ports2
- Output power12 W
- Operating temperature (T-T)0 - 40 °C
- Width80.8 mm
Overview
- Colour
- White
- Ethernet interface type
- Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 2
- Output power
- 12 W
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 80.8 mm
- Brand
- TP-Link
- Category
- PoE Adapter
- Model
- TL-POE10R
- Part number
- TL-POE10R V1
- EAN / UPC
- 5053313218254, 013044102197, 080050392898, 191120078311 +13 more
- Also known as
- TP-Link PoE Splitter
Specifications
27 specifications in 10 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.3af |
Features
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Power |
| Safety | FCC, CE |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| DC-in jack | Yes |
| I/O ports | PoE Port, LAN Port |
Power
| Specification | Value |
|---|---|
| Output power | 12 W |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Compliance industry standards | IEEE 802.3, 802.3u, 802.3af |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80.8 mm |
| Depth | 54 mm |
| Height | 24 mm |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 198 mm |
| Package depth | 165 mm |
| Package height | 65 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85044090 |
