I-SWHUB 3000STY2
Model I-SWHUB 3000STY2EAN 8058956621024
29 specifications
- Weight562 g
- ColourBlack
- Ethernet interface typeFast Ethernet, Gigabit Ethernet
- Ethernet LAN (RJ-45) ports2
- Output power30 W
- Operating temperature (T-T)0 - 50 °C
Overview
- Weight
- 562 g
- Colour
- Black
- Ethernet interface type
- Fast Ethernet, Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 2
- Output power
- 30 W
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- Techly
- Category
- PoE Adapter
- Model
- I-SWHUB 3000STY2
- Part number
- I-SWHUB 3000STY2
- EAN / UPC
- 8058956621024
- Also known as
- Techly I-SWHUB 3000STY2 PoE adapter Fast Ethernet, Gigabit Ethernet
Specifications
29 specifications in 8 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Cable types supported | Cat5, Cat5e |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Wall mountable | Yes |
| Maximum operating distance | 100 m |
| LED indicators | PoE, Power |
| Power protection features | Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
Power
| Specification | Value |
|---|---|
| Output power | 30 W |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50 - 60 Hz |
| Power consumption (max) | 35 W |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -20 - 80 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 57 mm |
| Depth | 130 mm |
| Height | 34 mm |
| Weight | 562 g |
Packaging content
| Specification | Value |
|---|---|
| Power cord included | Yes |
| Manual | Yes |
