Industrial Gigabit Ethernet PoE Injector
30W 802.3at PoE+ Midspan 48V-56VDC DIN Rail Power Over Ethernet Injector Adapter - -40C to +75C Cameras/
Model POEINJ30WEAN 065030891363
36 specifications
- Weight143 g
- ColourBlack
- Ethernet interface typeFast Ethernet, Gigabit Ethernet
- RJ-45 input ports1
- Input voltage48 - 56 V
- Operating temperature (T-T)-40 - 75 °C
Overview
- Weight
- 143 g
- Colour
- Black
- Ethernet interface type
- Fast Ethernet, Gigabit Ethernet
- RJ-45 input ports
- 1
- Input voltage
- 48 - 56 V
- Operating temperature (T-T)
- -40 - 75 °C
- Brand
- StarTech.com
- Category
- PoE Adapter
- Model
- POEINJ30W
- Part number
- POEINJ30W
- EAN / UPC
- 065030891363
- Also known as
- StarTech.com Industrial Gigabit Ethernet PoE Injector - 30W 802.3at PoE+ Midspan 48V-56VDC DIN Rail Power Over Ethernet Injector Adapter - -40C to +75C Cameras/
Specifications
36 specifications in 10 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Auto MDI/MDI-X | Yes |
| Duplex system | Full |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Supported network protocols | CSMA/CD |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Surge protection | Yes |
| Maximum operating distance | 100 m |
| LED indicators | Yes |
| Safety | MET (UL) 60950-1, EN60950-1 |
| Power protection features | Overload, Reverse polarity |
Ports & interfaces
| Specification | Value |
|---|---|
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
Power
| Specification | Value |
|---|---|
| Input voltage | 48 - 56 V |
| Power consumption (max) | 37 W |
| Power over Ethernet (PoE) power per port | 30 W |
| Power plug type | Type N |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, FCC, UL |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 85 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 143 g |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package length | 21.1 cm |
| Package width | 166 mm |
| Package depth | 214 mm |
| Package height | 69 mm |
| Package weight | 381 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85044095 |
| Master (outer) case width | 364 mm |
| Master (outer) case length | 370 mm |
| Master (outer) case height | 250 mm |
| Products per master (outer) case | 10 pc(s) |
