StarTech.com 1-Port 10Gbps PoE++ Injector
StarTech.com

1-Port 10Gbps PoE++ Injector

90W, 2.5/5/10G Ethernet/10/100/1000M, PoE++ (802.3af/at/bt), Wall Mountable, Unmanaged Inline Power Over Ethernet, TA

Model AF41XC-POE-INJECTOREAN 065030902212

43 specifications
  • Weight350 g
  • ColourBlack
  • Ethernet LAN data rates10000 Mbit/s
  • Ethernet LAN (RJ-45) ports2
  • AC adapter input voltage100 - 240 V
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Weight
350 g
Colour
Black
Ethernet LAN data rates
10000 Mbit/s
Ethernet LAN (RJ-45) ports
2
AC adapter input voltage
100 - 240 V
Operating temperature (T-T)
0 - 40 °C
Brand
StarTech.com
Category
PoE Adapter
Model
AF41XC-POE-INJECTOR
Part number
AF41XC-POE-INJECTOR
EAN / UPC
065030902212
Also known as
StarTech.com 1-Port 10Gbps PoE++ Injector, 90W, 2.5/5/10G Ethernet/10/100/1000M, PoE++ (802.3af/at/bt), Wall Mountable, Unmanaged Inline Power Over Ethernet, TA

Specifications

43 specifications in 9 groups

Network

Ethernet interface type2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates10000 Mbit/s
Cabling technology1000/10000
Power over Ethernet (PoE)Yes
Auto MDI/MDI-XYes
ChipsetSkyWorks - Si3471A-A01
Networking standardsIEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u
Web-based managementNo

Features

Product colourBlack
Housing materialPlastic
Wall mountableYes
Maximum operating distance100 m
LED indicatorsYes
Jumbo frames9000
Jumbo frames supportYes
Auto-negotiationYes
Power protection featuresOver current, Over voltage, Short circuit

Ports & interfaces

Ethernet LAN (RJ-45) ports2
RJ-45 input ports1
RJ-45 output ports1

Power

AC adapter input voltage100 - 240 V
AC adapter output voltage56 V
Input current1.5 A
Output current1.7 A
Total Power over Ethernet (PoE) budget90 W
Suitable for use in country/locationUnited States

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 90%
Storage temperature (T-T)-30 - 80 °C

Weight & dimensions

Width64 mm
Depth170 mm
Height34 mm
Weight350 g

Packaging content

Power cord includedYes
Quick installation guideYes

Packaging data

Package width212 mm
Package depth125 mm
Package height52 mm
Package weight600 g

Logistics data

Master (outer) case width286 mm
Master (outer) case length522 mm
Master (outer) case height455 mm
Products per master (outer) case40 pc(s)
