PoE Injector
56W
Model POI-4000-ZEAN 401586715485
24 specifications
- ColourBlack
- Ethernet interface typeFast Ethernet
- Ethernet LAN (RJ-45) ports2
- Power over Ethernet (PoE) voltage56 V
- Operating temperature (T-T)0 - 50 °C
- Dimensions (WxDxH)90 x 120 x 28 mm
Overview
- Colour
- Black
- Ethernet interface type
- Fast Ethernet
- Ethernet LAN (RJ-45) ports
- 2
- Power over Ethernet (PoE) voltage
- 56 V
- Operating temperature (T-T)
- 0 - 50 °C
- Dimensions (WxDxH)
- 90 x 120 x 28 mm
- Brand
- LevelOne
- Category
- PoE Adapter
- Model
- POI-4000-Z
- Part number
- POI-4000-Z
- EAN / UPC
- 401586715485, 4015867154854
- Also known as
- LevelOne PoE Injector, 56W
Specifications
24 specifications in 9 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3af |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Plug and Play | Yes |
| Maximum operating distance | 100 m |
| LED indicators | LAN, Power |
| Power protection features | Over current, Over voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) voltage | 56 V |
| Input voltage | 24 V |
| Input current | 2.7 A |
| Output current | 1 A |
| Power consumption (max) | 12.95 W |
| Total Power over Ethernet (PoE) budget | 56 W |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Rules Part 15 Class A CE |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 90 x 120 x 28 mm |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85044095 |
| Country of origin | Taiwan |
