Gigabit Ultra PoE+ Injector
1 x 60 W Port, IEEE 802.3bt and IEEE 802.3at/af Compliant, Plastic Housing (UK Power Cord)
Model 561235-UKEAN 766623995849
25 specifications
- Weight290 g
- ColourBlack
- Ethernet interface typeGigabit Ethernet
- Ethernet LAN (RJ-45) ports2
- Power over Ethernet (PoE) voltage48 V
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 290 g
- Colour
- Black
- Ethernet interface type
- Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 2
- Power over Ethernet (PoE) voltage
- 48 V
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Intellinet
- Category
- PoE Adapter
- Model
- 561235-UK
- Part number
- 561235-UK
- EAN / UPC
- 766623995849
- Also known as
- Intellinet Gigabit Ultra PoE+ Injector, 1 x 60 W Port, IEEE 802.3bt and IEEE 802.3at/af Compliant, Plastic Housing (UK Power Cord)
Specifications
25 specifications in 8 groups
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Duplex system | Full |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | PoE |
| Power protection features | Over current, Over voltage, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) voltage | 48 V |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Output current | 1.25 A |
| Power consumption (max) | 60 W |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B, CE |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 80 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 61 mm |
| Depth | 123 mm |
| Height | 40 mm |
| Weight | 290 g |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| Power cord included | Yes |
| Manual | Yes |
