WC7600 + 10x WAC720
Model WC7600 + 10x WAC720Part no. WB7620-10000SEAN 606449115925
36 specifications
- ConnectivityWired & Wireless
- Weight3.6 kg
- ColourBlack
- Number of users50 user(s)
- Ethernet LANYes
- AC input voltage100-240 V
Overview
- Connectivity
- Wired & Wireless
- Weight
- 3.6 kg
- Colour
- Black
- Number of users
- 50 user(s)
- Ethernet LAN
- Yes
- AC input voltage
- 100-240 V
- Brand
- NETGEAR
- Category
- Network Management Device
- Model
- WC7600 + 10x WAC720
- Part numbers
- WB7620-10000S, WB7620-100NAS
- EAN / UPC
- 606449115925, 10606449115922
- Also known as
- NETGEAR WC7600 + 10x WAC720 network management device Ethernet LAN Wi-Fi
Specifications
36 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| Number of users | 50 user(s) |
| Number of VLANs | 64 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11e, IEEE 802.11i, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| DHCP server | Yes |
| Access Control List (ACL) | Yes |
| Captive portal | Yes |
| VLAN support | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 4 |
| Console port | VGA |
| USB 2.0 ports quantity | 2 |
| AC (power) in | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 8 A |
| Power consumption (typical) | 13 W |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Rack capacity | 1U |
| Product colour | Black |
| Power LED | Yes |
| LED indicators | Power, Status |
| Certification | FCC, CE, WEEE, RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 440 x 43 x 262 mm |
| Weight | 3.6 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, LAN (RJ-45) |
| User guide | Yes |
