Epson WF-R5190 DTW BAM
Model WF-R5190 DTW BAMPart no. C11CE28402CWEAN 8715946647258
59 specifications
- Weight24.2 kg
- ColourYes
- Maximum resolution4800 x 1200 DPI
- Total input capacity580 sheets
- Maximum ISO A-series paper sizeA4
- Sound pressure level (printing)6.6 dB
Overview
- Weight
- 24.2 kg
- Colour
- Yes
- Maximum resolution
- 4800 x 1200 DPI
- Total input capacity
- 580 sheets
- Maximum ISO A-series paper size
- A4
- Sound pressure level (printing)
- 6.6 dB
- Brand
- Epson
- Category
- Inkjet Printer
- Model
- WF-R5190 DTW BAM
- Part number
- C11CE28402CW
- EAN / UPC
- 8715946647258
- Also known as
- Epson WF-R5190 DTW BAM inkjet printer Colour 4800 x 1200 DPI A4 Wi-Fi
Specifications
59 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum duty cycle | 45000 pages per month |
| Duplex printing | Yes |
| Page description languages | ESC/P-R, PCL 5c, PCL 5e, PCL 6, PDF 1.7, PostScript 3 |
| Printing colours | Black, Cyan, Magenta, Yellow |
Printing
| Specification | Value |
|---|---|
| Maximum resolution | 4800 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 34 ppm |
| Print speed (colour, draft quality, A4/US Letter) | 30 ppm |
| Time to first page (black, normal) | 7 s |
| Time to first page (colour, normal) | 7 s |
| Print speed (ISO/IEC 24734) colour | 16 ipm |
| Print speed (ISO/IEC 24734) mono | 16 ipm |
| Duplex print speed (black, normal quality, A4/US Letter) | 11 ppm |
| Duplex print speed (colour, normal quality, A4/US Letter) | 11 ppm |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 580 sheets |
| Total output capacity | 150 sheets |
| Maximum input capacity | 580 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Plain paper, Thick paper |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5 |
| ISO C-series sizes (C0...C9) | C4, C6 |
| Non-ISO print media sizes | Legal |
| Envelopes sizes | 10, C4, C6 |
| Photo paper sizes (imperial) | 10x15,13x18,20x25 |
| Paper tray media weight | 64 - 256 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| Standard interfaces | Ethernet, USB, Wireless LAN |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi Direct | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, AES, WPA-PSK, WPA2 |
| Mobile printing technologies | Apple AirPrint, Google Cloud Print |
Performance
| Specification | Value |
|---|---|
| Sound pressure level (printing) | 6.6 dB |
| Sound power level (printing) | 52 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | White |
| Built-in display | Yes |
| Display | LCD |
| Country of origin | Indonesia |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 25 W |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 2.3 W |
| Power consumption (ready) | 6.2 W |
| AC input voltage | 220 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Server operating systems supported | Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012 x64 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 664 mm |
| Depth | 435 mm |
| Height | 413 mm |
| Weight | 24.2 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Power cord included | Yes |
| Drivers included | Yes |
| Package width | 599 mm |
| Package depth | 870 mm |
| Package height | 680 mm |
| Package weight | 31.9 kg |
