Deskjet D1660 Printer
Model Deskjet D1660 PrinterPart no. CB770BEAN 884420931379
123 specifications
- Connectivity1 USB 2.0
- Weight2.2 kg
- ColourYes
- Maximum resolution4800 x 1200 DPI
- Total input capacity80 sheets
- Maximum ISO A-series paper sizeA4
Overview
- Connectivity
- 1 USB 2.0
- Weight
- 2.2 kg
- Colour
- Yes
- Maximum resolution
- 4800 x 1200 DPI
- Total input capacity
- 80 sheets
- Maximum ISO A-series paper size
- A4
- Brand
- HP
- Category
- Inkjet Printer
- Model
- Deskjet D1660 Printer
- Part number
- CB770B
- EAN / UPC
- 884420931379, 884420931386, 884420931416, 8844209313866
- Also known as
- HP Deskjet D1660 Printer inkjet printer Colour 4800 x 1200 DPI A4
Specifications
123 specifications in 15 groups
Features
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum duty cycle | 750 pages per month |
| Number of print cartridges | 2 |
| Electromagnetic compatibility | CISPR 22: 2005/EN 55022: 2006 Class B, CISPR 24: 1997+A1: 2001+A2: 2002/EN 55024: 1998+A1: 2001+ A2: 2003 Class B, IEC 61000-3-2: 2000+A1: 2001+A2: 2004/EN 61000-3-2: 2000+A2: 2005, IEC 61000-3-3: 1994+A1: 2001/EN 61000-3-3: 1995+A1: 2001, FCC CFR 47, Part 15 Class B/ICES-003, Issue 4 Class B |
| Safety | IEC 60950-1: 2001/EN 60950-1: 2001+A11: 2004; EU LVD&EN 60950 Compliant; Mexico NOM-NYCE; Russia GOST; China CCC; Taiwan BSMI |
| Print head nozzles | 336 (black), 1248 (tri-color) |
Printing
| Specification | Value |
|---|---|
| Maximum resolution | 4800 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 7 ppm |
| Print speed (colour, draft quality, A4/US Letter) | 16 ppm |
| Print speed (black, draft quality, A4/US Letter) | 20 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 5 ppm |
| Borderless printing | Yes |
| Print speed (colour, best quality, A4) | 2 ppm |
| Print speed (black, best quality, A4) | 4 ppm |
| Print quality (black, best quality) | 1200 |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 80 sheets |
| Total output capacity | 15 sheets |
| Maximum input capacity | 80 sheets |
| Maximum output capacity | 15 sheets |
| Envelope feeder | No |
| Standard input capacity for cards | 15 |
| Input capacity for envelopes (primary tray) | 10 sheets |
| Standard input capacity for transparencies | 15 |
| Standard output capacity for envelopes | 5 sheets |
| Standard output capacity for cards | 10 |
| Maximum output capacity for transparencies | 10 sheets |
| Maximum output capacity for envelopes | 5 sheets |
| Maximum output capacity for cards | 10 sheets |
| Duty cycle letter size (maximum) | 750 pages per month |
| Maximum input capacity for transparencies | 15 sheets |
| Maximum input capacity for labels | 15 |
| Maximum input capacity for envelopes | 10 |
| Maximum input capacity for cards | 40 |
| Maximum paper trays | 1 |
| Paper handling standard/input | 80-sheet input tray |
| Paper handling standard/output | 15 |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Card stock, Envelopes, Iron-On Transfers, Labels, Photo paper, Plain paper, Transparencies |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO C-series sizes (C0...C9) | C6 |
| Non-ISO print media sizes | Executive, Legal |
| Envelopes sizes | DL |
| Media size (tray 1) | A4 (210 x 297 mm); A5 (148 x 210 mm); B5 (176 x 250 mm); DL (110 x 220 mm); C6 (114 x 162 mm); A6 (105 x 148 mm); (300 x 100 mm); (130 x 180 mm); (100 x 150 mm) |
| Media weights by paper path | A4, legal, envelopes: 70 to 90 g/m²; cards: up to 200 g/m²; photos: up to 280 g/m² |
| Recommended media weight | 70 - 90 g/m² |
| Standard media sizes | A4; A5; A6; C6; DL |
| Custom media sizes | 77 x 127 - 216 x 356 mm 3 x 5 - 8.5 x 14 in |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| Direct printing | No |
| PictBridge | No |
| I/O ports | 1 USB 2.0 |
Performance
| Specification | Value |
|---|---|
| Maximum internal memory | Integrated |
| Acoustic power emissions | 6.1 B(A) |
| Acoustic pressure emissions | 48.1 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 20 W |
| Power consumption (off) | 0.32 W |
| Power consumption (standby) | 13 W |
| Power consumption (PowerSave) | 1.1 W |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Compatible operating systems | Windows Vista (32-bit & 64-bit); Windows XP (SP1 [32-bit]); Mac OS X v10.4, v10.5 |
| Minimum system requirements | Windows XP (SP1) or higher: any Intel Pentium II, Celeron or compatible processor; 233 MHz or higher; 128 MB RAM (256 MB or higher recommended); 600 MB hard disk space; Internet Explorer 6 or higher; CD-ROM/DVD drive or Internet connection; USB port; Windows Vista: 800 MHz 32-bit (x86) or 64-bit (64 |
| Minimum system requirements for Macintosh | Mac OS X v 10.4 / v 10.5; Power PC G3, G4, G5 / Intel Core; 256 MB RAM; 500 MB; CD-ROM/DVD/ Internet; USB |
| JetDirect Compatible Products | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 59 - 86 °F |
| Recommended operating temperature range (T-T) | 15 - 30 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.2 kg |
| Pallet dimensions (W x D x H) | 1219.2 x 1016 x 2527 mm |
Packaging data
| Specification | Value |
|---|---|
| Bundled software | Windows Live Photo Gallery |
| Package weight | 3.42 kg |
| Package weight (imperial) | 3.42 kg (7.53 lbs) |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) cases per pallet | 8 pc(s) |
| Layers per pallet | 9 pc(s) |
| Pallet size (EU) | 1200 x 800 x 2304 mm |
Other features
| Specification | Value |
|---|---|
| Network ready | No |
| Dimensions (WxDxH) | 432 x 198 x 158 mm |
| Functions | |
| Interface | 1 USB 2.0 |
| Media types supported | Paper (plain, Inkjet, photo); envelopes; transparencies; labels; cards; HP premium media; iron-on transfers |
| Power requirements | 100 - 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz) |
| Print head | CMYK |
| Print quality, vertical alignment accuracy | +/- 0.17 mm +/- 0.01 in |
| Print technology | Inkjet |
| Size (imperial) | 43.2 cm (17") |
| Standard input trays | 1 |
| Wireless technology | Not applicable |
| Package dimensions (WxDxH) | 481 x 189 x 240 mm |
| Maximum print length | 0.356 m |
| Compatible ink types, supplies | Pigment-based; dye-based |
| Duplex print options | Manual (driver support provided) |
| Automatic paper sensor | No |
| Camera phone | No |
| Control panel | Power (On/Off) |
| Maximum input capacity (photo paper) | 30 sheets |
| Maximum input capacity for 10 x 15 cm photographs | 30 sheets |
| Maximum output capacity (photo paper) | 10 sheets |
| Maximum output capacity for labels | 10 sheets |
| Maximum print length (imperial) | 14 in |
| Media sizes supported (imperial) | Letter; legal; executive; No 10 envelopes; cards |
| Package dimensions (W x D x H) | 481.1 x 189 x 240 mm (18.9 x 7.44 x 9.45") |
| Page yield identifier | DJD1600 |
| Pallet dimensions (W x D x H) (imperial) | 1219.2 x 1016 x 2527 mm (48 x 40 x 99.5") |
| Photo proofsheets supported | No |
| Print speed (black, best quality, letter) | 4 ppm |
| Print speed (colour, best quality, letter) | 2 ppm |
| Print speed (colour, draft quality, letter) | 16 ppm |
| Recommended media weight (imperial) | 20 lb |
| Skew | +/- 0.006 in |
| Skew (transparency) | +/- 0.012 in |
| Standard input capacity for legal | 80 sheets |
| Standard output capacity for labels | 10 sheets |
| Standard output capacity for legal | 15 sheets |
| Standard output capacity for transparencies | 10 sheets |
| SureSupply connection type | Direct |
| SureSupply supported | Yes |
| Video action printing supported | No |
| Weight (imperial) | 2.2 kg (4.85 lbs) |
