Officejet K5400 inkjet printer Colour
4800 x 1200 DPI
Model K5400Part no. C8184AEAN 882780700475
141 specifications
- Memory32 MB
- Weight8.8 kg
- ColourYes
- Maximum resolution4800 x 1200 DPI
- Total input capacity250 sheets
- Maximum print size215 x 355 mm
Overview
- Memory
- 32 MB
- Weight
- 8.8 kg
- Colour
- Yes
- Maximum resolution
- 4800 x 1200 DPI
- Total input capacity
- 250 sheets
- Maximum print size
- 215 x 355 mm
- Brand
- HP
- Category
- Inkjet Printer
- Model
- K5400
- Part number
- C8184A
- EAN / UPC
- 882780700475, 808736819749, 808736819756, 808736819763 +16 more
- Also known as
- HP Officejet K5400 inkjet printer Colour 4800 x 1200 DPI
Specifications
141 specifications in 15 groups
Features
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum duty cycle | 7500 pages per month |
| Number of print cartridges | 4 |
| Duplex printing | O |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Electromagnetic compatibility | FCC Title 47 CFR Part 15 Class B (USA), CE (European Union), ICES (Canada), VCCI (Japan), MIC (Korea), BSMI (Taiwan), China S&E (China) |
| Safety | CE (European Union), FCC Title 47 CFR Part 15 Class B (USA), ICES (Canada), Japan (VCCI), Korea (MIC), China (Requirements for Class B Products), Taiwan (BSMI), Mexico NOM-NYCE, Russia GOST, IEC 60950 compliant, USA UL listed, EU LVD, EN 60950 compliant, NEMKO GS, Canada CSA, China CCC, Taiwan BSMI, |
| Print head nozzles | 1056 black ink nozzles, 1056 ink nozzles per colour |
Printing
| Specification | Value |
|---|---|
| Maximum resolution | 4800 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 16, 12 |
| Print speed (colour, draft quality, A4/US Letter) | 35 ppm |
| Print speed (black, draft quality, A4/US Letter) | 36 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 15 ppm |
| Print margin top (A4) | 3.3 mm |
| Print margin right (A4) | 3.3 mm |
| Print margin left (A4) | 3.3 mm |
| Print margin bottom (A4) | 3.3 mm |
| Print speed (colour, full-page colour, best quality, A4) | 2.5 ppm |
| Print speed (colour, best quality, A4) | 5 ppm |
| Print speed (black, best quality, A4) | 5 ppm |
| Print quality (black, best quality) | 1200 x 1200 DPI |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 250 sheets |
| Total output capacity | 150 sheets |
| Maximum output capacity | 150 sheets |
| Paper input type | Paper tray |
| Envelope feeder | No |
| Standard input capacity for cards | Up to 80 cards |
| Input capacity for envelopes (primary tray) | envelopes |
| Standard output capacity for envelopes | 15 sheets |
| Standard output capacity for cards | Up to 60 cards |
| Maximum input capacity for envelopes | 30 |
| Maximum paper trays | 2 |
| Media size (tray 2) | A4, B5, 182 x 257 to 216 x 356 mm |
| Media type and capacity (tray 2) | sheets: 350 |
| Paper handling standard/input | 250-sheet input tray |
| Paper handling standard/output | 150-sheet output tray |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | 215 x 355 mm |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Media size (tray 1) | A4, A5, A6, B5, 76 x 127 to 216 x 356 mm |
| Media weight (tray 1) | 60 to 105 g/m² (plain media), 60 to 280 g/m² (special media), up to 200 g/m² (card media) |
| Duplex media weight | 60 - 105 (plain media), 60 - 200 (special media), up - 200 (card media) |
| Media weights by paper path | Tray 1: plain media: 60 to 105 g/m2, special media: 60 to 280 g/m2, cards media: up to 200 g/m2; Tray 2: plain media: 60 to 105 g/m2 |
| Recommended media weight | 75 - 90 g/m² |
| Standard media sizes | A4 (210 x 297 mm), A5 (148 x 210 mm), A6 (105 x 148 mm), B5 (176 x 250 mm), C5 (162 x 229 mm), C6 (114 x 162 mm), 100 x 150 mm, 130 x 180 mm |
| Custom media sizes | 76 x 127 to 216 x 356 mm |
| Duplex supported media size | A4, A5, B5, executive, letter, card (4 x 6 in, 5 x 8 in, A6) |
| Media handling | Sheetfed |
| Media weight (tray 2) | 60 to 105 g/m² (plain media) |
| Paper handling optional/input | Optional 350-sheet paper tray |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Direct printing | No |
| PictBridge | No |
| Standard interfaces | USB 2.0 |
| I/O ports | 1 Hi-Speed USB port - compatible with USB 2.0 specifications |
| Wireless option type | Optional, with HP Jetdirect Wireless Print Server |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32 MB |
| Maximum internal memory | 32 MB |
| Memory slots | 1 |
| Card reader integrated | No |
| Compatible memory cards | Not supported |
| Processor frequency | 192 MHz |
| Sound pressure level (printing) | 61 dB |
| Memory upgrade | No |
| Acoustic power emissions | 6.6 B(A) (active) |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | Black, Silver |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimat |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
| Compatible operating systems | Microsoft Windows 2000 (SP4), XP Home, XP Professional, XP Professional x64; Certified for Windows Vista; Mac OS X v10.3.9, v10.4.9, v10.5 |
| Minimum system requirements | Microsoft Windows 2000 (SP4): Intel Pentium II or Celeron processor, 128 MB RAM, 280 MB free hard disk space, Microsoft Internet Explorer 6.0; Microsoft Windows XP (32-bit): Intel Pentium II or Celeron processor, 512 MB RAM, 280 MB free hard disk space, Microsoft Internet Explorer 6.0; Microsoft Win |
| Minimum system requirements for Macintosh | Mac OS X v10.3.9, v10.4.9, v10.5*: PowerPC G3, G4, G5, or Intel Core Duo processor, 256 MB memory, 300 MB free hard disk space, QuickTime 5.0 or higher, CD-ROM drive, USB port (* Software is available for download from: /support) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 15 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 85% |
| Operating temperature (T-T) | 68 - 86 °F |
| Recommended operating temperature range (T-T) | 20 - 30 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 495 mm |
| Depth | 382 mm |
| Height | 207 mm |
| Weight | 8.8 kg |
| Pallet dimensions (W x D x H) | 1219 x 1016 x 2155 mm |
Packaging data
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Power cord included | Yes |
| Drivers included | Yes |
| Manual | Yes |
| Bundled software | HP Solution Center |
| Package weight | 13 kg |
| Package weight (imperial) | 13 kg (28.7 lbs) |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross weight | 332 kg |
| Master (outer) cases per pallet | 6 pc(s) |
| Layers per pallet | 4 pc(s) |
| Products per pallet | 24 pc(s) |
Other features
| Specification | Value |
|---|---|
| Printer management | HP Web Jetadmin |
| Network ready | No |
| Dimensions (WxDxH) | 495 x 382 x 207 mm |
| Interface | Hi-Speed USB port - compatible with USB 2.0 specifications |
| Media types supported | Paper (plain, inkjet, photo), envelopes, brochure paper, transparencies, labels, cards (index, greeting), photo media |
| Networking features | No |
| Power requirements | Input voltage 110 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz); 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz) |
| Print cartridge volume (metric) | HP 88XL Print Cartridge: black (58.5 ml), cyan (17 ml), magenta (17 ml), yellow (17 ml); HP 88 Print Cartridge: black (20.5 ml), cyan (9 ml), magenta (9 ml), yellow (9 ml) |
| Print head | 2 (1 black/yellow, 1 magenta/cyan) |
| Print technology | Thermal inkjet |
| Product dimensions when open (LxWxD) | 49.5 cm (19.5") |
| Size (imperial) | 49.5 cm (19.5") |
| Standard input trays | 1 |
| Wireless technology | 802.11b; 802.11g (optional) |
| Package dimensions (WxDxH) | 302 x 598 x 503 mm |
| Compatible ink types, supplies | Pigment-based (black), dye-based (colour) |
| Printer smart software features | Accepts a variety of paper sizes and types, automatic duplex (optional) |
| Duplex print options | None |
| Typefaces | 8 built-in fonts, 4 each in portrait and landscape orientation; CG Times, CG Times Italic, Univers, Univers Italic, Courier, Courier Italic, Letter Gothic, Letter Gothic Italic (Euro symbol supported) |
| Automatic paper sensor | No |
| Case or master carton quantity | 1 pc(s) |
| Control panel | 3 buttons (Power, Job cancel, Resume), 2 LEDs (Attention, Ready), 4 LEDs for supplies, 2 LEDs for printhead; LED display |
| Driver updates | Latest driver updates available at /support/ |
| Maximum input capacity for 10 x 15 cm photographs | 55 sheets |
| Maximum print length (imperial) | US legal |
| Media sizes supported (imperial) | Letter, legal, statement, executive, envelopes (No. 10, Monarch), cards (index), borderless photo (4 x 6 in, 5 x 7 in, 8 x 10 in), borderless panorama (4 x 10 in, 4 x 11 in, 4 x 12 in) |
| Media thickness (by paper path) | Tray 1: up to 11.8 mil; envelopes: up to 15.7 mil; Tray 2: up to 11.8 mil |
| Operating altitude (imperial) | 10000 ft |
| Package dimensions (W x D x H) | 596.9 x 302.3 x 502.9 mm (23.5 x 11.9 x 19.8") |
| Page yield identifier | OJ K5400 |
| Pallet dimensions (W x D x H) (imperial) | 1219.2 x 1016 x 2153.9 mm (48 x 40 x 84.8") |
| Pallet weight (imperial) | 332 kg (731.9 lbs) |
| Print speed (black, best quality, letter) | < 5 |
| Print speed (colour, best quality, letter) | < 5 |
| Print speed (colour, draft quality, letter) | < 35 |
| Recommended media weight (imperial) | 20 to 24 lb |
| Standard output capacity for transparencies | 60 sheets |
| SureSupply connection type | Direct and Network |
| SureSupply supported | Yes |
| Technical features | Laser Quality Speeds of up to 12 ppm black/10 ppm colour. Economical printing with individually replaceable HP Vivera ink cartridges, each linked into a unique ink recirculation system for maximum ink efficiency. Optional high capacity cartridges available (not included, purchase separately). Print |
| Upgrade type | Not applicable |
| Vivera inks supported | No |
| Weight (imperial) | 19.4 lb |
