WF-C8190DW BAM
Model WF-C8190DW BAMPart no. C11CG70401AAEAN 8715946708607
65 specifications
- Display6.1 cm (2.4")
- Weight35.3 kg
- ColourYes
- Maximum resolution4800 x 1200 DPI
- Total number of input trays3
- Maximum ISO A-series paper sizeA3
Overview
- Display
- 6.1 cm (2.4")
- Weight
- 35.3 kg
- Colour
- Yes
- Maximum resolution
- 4800 x 1200 DPI
- Total number of input trays
- 3
- Maximum ISO A-series paper size
- A3
- Brand
- Epson
- Category
- Inkjet Printer
- Model
- WF-C8190DW BAM
- Part number
- C11CG70401AA
- EAN / UPC
- 8715946708607
- Also known as
- Epson WorkForce Pro WF-C8190DW BAM inkjet printer Colour 4800 x 1200 DPI A3 Wi-Fi
Specifications
65 specifications in 13 groups
Features
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum duty cycle | 75000 pages per month |
| Duplex printing | Yes |
| Duplex printing mode | Auto |
| Page description languages | PCL 5c, PCL 6, ESC/P-R, PostScript 3, PDF 1.7 |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Print head nozzles | 800 nozzles black, 800 nozzles per colour |
Printing
| Specification | Value |
|---|---|
| Maximum resolution | 4800 x 1200 DPI |
| Time to first page (black, normal) | 5.5 s |
| Time to first page (colour, normal) | 5.5 s |
| Duplex print speed (ISO/IEC 24734, A4) black | 16 ppm |
| Duplex print speed (ISO/IEC 24734, A4) colour | 16 ppm |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 3 |
| Total input capacity | 250 sheets |
| Total output capacity | 250 sheets |
| Maximum number of input trays | 3 |
| Maximum input capacity | 1835 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Paper tray media types | Thick paper |
| ISO A-series sizes (A0...A9) | A3, A3+, A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B4, B5, B6 |
| Envelopes sizes | 10, C4, C5, C6, DL |
| Photo paper sizes | 10x15,13x18,20x25 |
| Paper tray media weight | 64 - 300 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| Direct printing | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi Direct | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA-AES, WPA2-Enterprise |
| Supported network protocols | TCP/IPv4, TCP/IPv6 |
| Mobile printing technologies | Epson Connect, Epson iPrint, Epson Email Print, Epson Remote Print, Apple AirPrint, Google Cloud Print |
Performance
| Specification | Value |
|---|---|
| Sound pressure level (printing) | 51 dB |
| Sound power level (printing) | 6.7 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | White |
| Built-in display | Yes |
| Display | LCD |
| Colour display | Yes |
| Display diagonal | 6.1 cm (2.4") |
| Country of origin | Indonesia |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 37 W |
| Power consumption (off) | 0.2 W |
| Power consumption (standby) | 1.2 W |
| Power consumption (ready) | 8.5 W |
| Energy Star Typical Electricity Consumption (TEC) | 0.2 kWh/week |
| AC input voltage | 220 - 240 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2012 x64, Windows Server 2016 |
| Other operating systems supported | Android |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 613 mm |
| Depth | 755 mm |
| Height | 386 mm |
| Weight | 35.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Cables included | AC |
| Package width | 690 mm |
| Package depth | 775 mm |
| Package height | 765 mm |
| Package weight | 52.8 kg |
Other features
| Specification | Value |
|---|---|
| Printing method | Epson PrecisionCore |
| Ink drop | 4.6 |
