HTS3366 Hi-Speed USB 2.0 Link DVD home theater system
Model HTS3366/98EAN 8712581389413
116 specifications
- ColourBlack
- Optical disc player typeDVD player
- 3DNo
- Audio output channels5.1 channels
- FM radioYes
- Center speaker type3-way
Overview
- Colour
- Black
- Optical disc player type
- DVD player
- 3D
- No
- Audio output channels
- 5.1 channels
- FM radio
- Yes
- Center speaker type
- 3-way
- Brand
- Philips
- Category
- Home Cinema System
- Model
- HTS3366/98
- Part number
- HTS3366/98
- EAN / UPC
- 8712581389413
- Also known as
- Philips HTS3366 Hi-Speed USB 2.0 Link DVD home theater system
Specifications
116 specifications in 17 groups
Optical drive
| Specification | Value |
|---|---|
| Optical disc player type | DVD player |
| Disc types supported | CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW |
| Playback disc formats | CD audio, CD video, SVCD, VCD |
Video
| Specification | Value |
|---|---|
| 3D | No |
| Video formats supported | DIVX, MPEG1, MPEG2, MPEG4, WMV |
| Full HD | Yes |
| Video D/A Converter (DAC) | 12-bit/108MHz |
| Analog signal format system | NTSC, PAL |
| Progressive scan | Yes |
| Video upscaling | Yes |
Audio
| Specification | Value |
|---|---|
| Audio output channels | 5.1 channels |
| RMS rated power | 600 W |
| Audio decoders | Dolby Digital, Dolby Pro Logic II, DTS |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
| Signal-to-Noise Ratio (SNR) | 65 dB |
| Audio formats supported | MP3, WMA |
| Equalizer | Yes |
| Sound enhancement technology | Yes |
| MP3 bit rates | 32 - 256 Kbit/s |
Radio
| Specification | Value |
|---|---|
| FM radio | Yes |
| Supported radio bands | FM |
| Preset stations quantity | 40 |
Center speaker
| Specification | Value |
|---|---|
| Center speaker type | 3-way |
| Center speaker frequency range | 150 - 20000 Hz |
| Center speaker impedance | 6 Ω |
| Center speaker tweeter diameter | 5.08 cm (2") |
| Center speaker woofer diameter (imperial) | 6.35 cm (2.5") |
Satellite speakers
| Specification | Value |
|---|---|
| Number of satellite speakers | 2 |
| Satellite speaker frequency range | 150 - 20000 Hz |
| Satellite speaker impedance | 3 Ω |
| Satellite speaker woofer diameter (imperial) | 7.62 cm (3") |
| Wireless satellite speakers | No |
Subwoofer
| Specification | Value |
|---|---|
| Subwoofer type | Passive subwoofer |
| Subwoofer RMS power | 150 W |
| Wireless subwoofer | No |
| Subwoofer driver diameter (imperial) | 16.5 cm (6.5") |
| Subwoofer frequency range | 40 - 150 Hz |
| Subwoofer impedance | 6 Ω |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI in | 0 |
| Number of HDMI outputs | 1 |
| SCART ports quantity | 0 |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| S-Video outputs quantity | 1 |
| AUX in | Yes |
| Digital audio coaxial in | 1 |
| Digital audio coaxial out | 0 |
| Digital audio optical in | 0 |
| Digital audio optical out | 0 |
| Ethernet LAN (RJ-45) ports | 0 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 100 W |
| AC input frequency | 50 - 60 Hz |
| Power consumption (standby) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Main unit dimensions (WxDxH) | 435 x 360 x 58 mm |
| Main unit weight | 3.7 kg |
| Front speaker dimensions (WxDxH) | 203 x 71 x 103 mm |
| Front speaker weight | 540 g |
| Center speaker dimensions (WxDxH) | 105 x 75 x 440 mm |
| Center speaker weight | 1.39 kg |
| Satellite speaker dimensions (WxDxH) | 262 x 264 x 1199 mm |
| Satellite speaker weight | 3.53 kg |
| Subwoofer dimensions (W x D x H) | 363 x 369 x 163 mm |
| Subwoofer weight | 5.08 kg |
| Rear speaker weight | 3.53 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 970 mm |
| Package depth | 410 mm |
| Package height | 435 mm |
| Package weight | 22.4 kg |
| Package dimensions (WxDxH) | 970 x 410 x 435 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Composite |
| Manual | Yes |
| Quick start guide | Yes |
| Remote control included | Yes |
| Warranty card | Yes |
Other features
| Specification | Value |
|---|---|
| Apple docking compatibility | Not supported |
| Built-in HDD | No |
| TV tuner integrated | No |
| Audio system | DTS, Dolby Digital, Dolby Prologic II, Stereo |
| CD-RW playback | Yes |
| Center speaker depth | 7.5 cm |
| Center speaker height | 10.5 cm |
| Center speaker width | 44 cm |
| Depth | 360 mm |
| Front speaker depth | 7.1 cm |
| Front speaker height | 20.3 cm |
| Front speaker width | 10.3 cm |
| Height | 58 mm |
| Image formats supported | JPG |
| MP3 playback | Yes |
| Package weight | 22.2 kg |
| Rear speaker depth | 26.4 cm |
| Rear speaker height | 119.9 cm |
| Rear speaker width | 26.2 cm |
| Subwoofer | Yes |
| Subwoofer depth | 36.9 cm |
| Subwoofer height | 36.3 cm |
| Subwoofer width | 16.3 cm |
| Packaging net weight | 18.85 kg |
| Packaging tare weight | 3.35 kg |
| Set weight | 3.7 kg |
| Set width | 43.5 cm |
Certificates
| Specification | Value |
|---|---|
| Consumer Electronics Control (CEC) | EasyLink |
Outer carton
| Specification | Value |
|---|---|
| Gross weight of outer carton | 22.2 kg |
| Height (cm) outer carton | 43.5 cm |
| Length (cm) outer carton | 97 cm |
| Net weight of outer carton | 18.85 kg |
| Tare weight outer carton | 3.35 kg |
| Width (cm) outer carton | 41 cm |
Technical details
| Specification | Value |
|---|---|
| Product colour | Black |
| Karaoke | Yes |
| Frequency range | 150 - 18000 Hz |
| Slideshow | Yes |
