D2-310 12TB 2x6TB Seagate IronWolf 2 Bay NAS Desktop
Model D2-310 12TB 2x6TB Seagate IronWolf 2 Bay NAS DesktopPart no. D2-310/12TB-IW
41 specifications
- Noise18.6 dB
- ColourSilver
- Storage drives installedYes
- Device classHome & Home Office
- Power supply unit (PSU) capacity40 W
- Width119 mm
Overview
- Noise
- 18.6 dB
- Colour
- Silver
- Storage drives installed
- Yes
- Device class
- Home & Home Office
- Power supply unit (PSU) capacity
- 40 W
- Width
- 119 mm
- Brand
- TerraMaster
- Category
- Disk Array
- Model
- D2-310 12TB 2x6TB Seagate IronWolf 2 Bay NAS Desktop
- Part number
- D2-310/12TB-IW
- Also known as
- TerraMaster D2-310 12TB 2x6TB Seagate IronWolf 2 Bay NAS Desktop disk array Silver
Specifications
41 specifications in 9 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 2 |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 2 |
| Maximum supported storage capacity | 32 TB |
| Storage drive interface | Serial ATA |
| Supported storage drive interfaces | Serial ATA |
| Storage drive sizes supported | 2.5,3.5" |
| RAID levels | 0, 1, JBOD |
| Data transfer rate | 5 Gbit/s |
| Hot-swap drive bays | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | Yes |
Design
| Specification | Value |
|---|---|
| Device class | Home & Home Office |
| Chassis type | Desktop |
| Product colour | Silver |
| LED indicators | HDD, Power |
| Cooling | Yes |
| Noise level | 18.6 dB |
| Number of fans | 1 fan(s) |
| Fan diameter | 8 cm |
| Certification | CE, FCC, CCC, KC, WEEE |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 40 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 25.6 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| DC output voltage | 12 V |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Mac operating systems supported | macOS |
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 119 mm |
| Depth | 133 mm |
| Height | 227 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, USB Type-A to USB Type-C |
| Number of adapters included | 1 pc(s) |
| Screws included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
