VS-UVR5004EVO-BS2 digital video recorder (DVR) White
Model VS-UVR5004EVO-BS2EAN 8052780302258
31 specifications
- ColourWhite
- Maximum video resolution1920 x 1080 pixels
- Video input channels6 channels
- Ethernet LANYes
- Number of HDDs supported1
- Power supply typeDC
Overview
- Colour
- White
- Maximum video resolution
- 1920 x 1080 pixels
- Video input channels
- 6 channels
- Ethernet LAN
- Yes
- Number of HDDs supported
- 1
- Power supply type
- DC
- Brand
- Vultech Security
- Category
- Digital Video Recorders (DVR)
- Model
- VS-UVR5004EVO-BS2
- Part number
- VS-UVR5004EVO-BS2
- EAN / UPC
- 8052780302258
- Also known as
- Vultech Security VS-UVR5004EVO-BS2 digital video recorder (DVR) White
Specifications
31 specifications in 8 groups
Performance
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Audio formats supported | G.711 A-law |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Video capturing speed | 30 fps |
| Channels quantity | 6 channels |
| Product colour | White |
Ports & interfaces
| Specification | Value |
|---|---|
| Video input channels | 6 channels |
| BNC input ports | 4 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| Audio input | RCA |
| Audio output | RCA |
| USB 2.0 ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | TCP/IP, P2P, HTTP, HTTPS, DHCP, DNS, DDNS, RTSP, SMTP, MULTICAST, NTP, UPNP™, SNMP, FTP, 3G/4G, Wi-Fi, Cloud Storage |
Hard drive
| Specification | Value |
|---|---|
| Number of HDDs supported | 1 |
| HDD interface | SATA |
| Maximum HDD capacity | 1 TB |
Power
| Specification | Value |
|---|---|
| Power supply type | DC |
| DC voltage | 12 V |
| Power consumption (typical) | 15 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 196 mm |
| Depth | 196 mm |
| Height | 48 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Mouse included | Yes |
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 50 °C |
