XVR1B04H-I/T + 4 HAC-B2A51
Dahua Technology

XVR1B04H-I/T + 4 HAC-B2A51

Model XVR1B04H-I/T + 4 HAC-B2A51Part no. DHI-KIT/XVR1B04H-I/T/4-B2A51N-U-IL-A-0280B-S3-DIP

75 specifications
  • Resolution1920 x 1080 pixels
  • OSEmbedded LINUX
  • Weight580 g
  • Maximum video resolution2592 x 1944 pixels
  • Video input channels6 channels
  • Ethernet LANYes
See all specifications

Overview

Resolution
1920 x 1080 pixels
OS
Embedded LINUX
Weight
580 g
Maximum video resolution
2592 x 1944 pixels
Video input channels
6 channels
Ethernet LAN
Yes
Brand
Dahua Technology
Model
XVR1B04H-I/T + 4 HAC-B2A51
Part number
DHI-KIT/XVR1B04H-I/T/4-B2A51N-U-IL-A-0280B-S3-DIP
Also known as
Dahua Technology XVR1B04H-I/T + 4 HAC-B2A51

Specifications

75 specifications in 13 groups

Performance

Maximum video resolution2592 x 1944 pixels
Audio formats supportedG.711, G.711u, PCM
Video compression formatsH.265, H.264
Video recording trigger modesAlarm, Motion detection
InternalNo
Backup functionYes
Video loss detectionYes
Video motion detectionYes
Audio bitrate64 Kbit/s
Audio input channels1 channels
Audio output channels1.0 channels
Audio streamingYes
Audio system2-way
Bit rate6144 Kbit/s
Channels quantity6 channels
Display1 HDMI, 1 VGA
Dual stream supportYes
Event loggingYes
Input bandwidth32 Mbit/s
Multi-display modes1, 4, 6
Multi-display supportedYes
Network connection typeRJ-45
Number of simultaneously playbacked channels1 channels
Operating system installedEmbedded LINUX
Playback modesInstant, General, Event, Tag, Smart
Playback resolutions supported1920 × 1080, 1280 × 1024, 1280 × 720
Remote viewingYes
Total bandwidth32 Mbit/s
USB connectivityYes
Video output - digitalHDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Video streamingYes
Compatible operating systemsEmbedded Linux; Web; Local GUI; iOS; Android; Chrome; IE; Safari; Edge; Firefox

Video

Video resolutions1920 x 1080,1280 x 1024,1280 x 720,2592 x 1944,2304 x 1296

Ports & interfaces

Video input channels6 channels
BNC input ports4
HDMI ports quantity1
VGA (D-Sub) output ports1
Audio input1-channel RCA; 4-channel BNC (Coaxial Audio)
Audio output1-channel RCA
USB 2.0 ports quantity2
Video in4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
Video out1 HDMI, 1 VGA
Number of HDMI outputs1
eSATA ports quantity1

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet interface typeFast Ethernet
Ethernet LAN data rates100,1000 Mbit/s
Supported network protocolsHTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

Hard drive

Maximum HDD capacity16 TB
Supported HDD interfacesSerial ATA
Media types supportedSATA

Processor

Built-in processorYes

Power

Power supply typeDC
DC voltage12 V
DC current (max)1.5 A
Power consumption (typical)4 W
Power requirements12 VDC, 1.5 A

Weight & dimensions

Width197 mm
Depth204.3 mm
Height41.5 mm
Weight580 g

Packaging data

Package width332 mm
Package depth64 mm
Package height240 mm
Package weight1.13 kg

Display

Built-in displayYes
Display resolution1920 x 1080 pixels

Features

Audible alarm(s)Yes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-10 - 45 °C
Storage temperature (T-T)-20 - 60 °C

Technical details

Audio channels1
Package volume5008.88 cm³
Shipping (inner) case gross weight1.13 kg
