XVR5216A-4KL-I2 digital video recorder (DVR) Black, Grey

Model XVR5216A-4KL-I2EAN 6939554992810

56 specifications

OSLinux
Weight1.9 kg
ColourBlack, Grey
Maximum video resolution3840 x 2160 pixels
Video input channels16 channels
Ethernet LANYes

See all specifications

Overview

OS: Linux
Weight: 1.9 kg
Colour: Black, Grey
Maximum video resolution: 3840 x 2160 pixels
Video input channels: 16 channels
Ethernet LAN: Yes

Brand: Dahua Technology
Category: Digital Video Recorders (DVR)
Model: XVR5216A-4KL-I2
Part number: XVR5216A-4KL-I2
EAN / UPC: 6939554992810
Also known as: Dahua Technology XVR5216A-4KL-I2 digital video recorder (DVR) Black, Grey

Specifications

56 specifications in 11 groups

Performance

Specification	Value
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Internal	No
Backup function	Yes
Video loss detection	Yes
Video motion detection	Yes
Analog signal format system	NTSC, PAL
Audio system	2-way
Channels quantity	16 channels
Dual stream support	Yes
LED indicators	Yes
Maximum frame rate	30 fps
Maximum recording time	1 h
Multi-display modes	2, 4, 8, 9, 16, 25, 36
Multi-display supported	Yes
Operating system installed	Linux
PTZ control	Yes
Playback modes	Full screen, Next, Pause, Play, Previous, Repeat, Shuffle, Stop
Playback resolutions supported	HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Product colour	Black, Grey
USB connectivity	Yes
Video streaming	Yes
Rack capacity	1U
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024

Ports & interfaces

Specification	Value
Video input channels	16 channels
Alarm input channels	16
HDMI ports quantity	1
VGA (D-Sub) output ports	1
Audio input	4
Audio output	1
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RS-485 ports	1
Relay outputs	3

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Ethernet interface type	Gigabit Ethernet
Number of users	128 user(s)
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search

Hard drive

Specification	Value
Number of HDDs supported	2
HDD interface	Serial ATA
Maximum HDD capacity	10 TB

Processor

Specification	Value
Built-in processor	Yes

Power

Specification	Value
Power supply type	DC
DC voltage	12 V
Power consumption (max)	15 W

Weight & dimensions

Specification	Value
Width	375 mm
Depth	288 mm
Height	53 mm
Weight	1.9 kg

Packaging data

Specification	Value
Package weight	3.2 kg

Display

Specification	Value
Built-in display	No

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 55 °C
Storage temperature (T-T)	-20 - 70 °C

Technical details

Specification	Value
Compliance certificates	CE
Sustainability compliance	Yes
