XVR5416L-I3 digital video recorder (DVR) Black
Model XVR5416L-I3
27 specifications
- OSEmbedded LINUX
- Weight4.45 kg
- ColourBlack
- Maximum video resolution1920 x 1080 pixels
- Video input channels16 channels
- Built-in processorYes
Overview
- OS
- Embedded LINUX
- Weight
- 4.45 kg
- Colour
- Black
- Maximum video resolution
- 1920 x 1080 pixels
- Video input channels
- 16 channels
- Built-in processor
- Yes
- Brand
- Dahua Technology
- Category
- Digital Video Recorders (DVR)
- Model
- XVR5416L-I3
- Part number
- XVR5416L-I3
- Also known as
- Dahua Technology XVR5416L-I3 digital video recorder (DVR) Black
Specifications
27 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Internal | No |
| Video capturing speed (NTSC) | 30 fps |
| Video capturing speed (PAL) | 25 fps |
| Video loss detection | Yes |
| Video motion detection | Yes |
| Graphical user interface (GUI) | Yes |
| Operating system installed | Embedded LINUX |
| Product colour | Black |
| Video streaming | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Video input channels | 16 channels |
| Alarm input channels | 16 |
| BNC input ports | 16 |
| HDMI ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | AC |
| AC input voltage | 100 - 240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 420.2 mm |
| Height | 76 mm |
| Weight | 4.45 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 529 mm |
| Package depth | 499 mm |
| Package height | 211 mm |
| Package weight | 6.75 kg |
