Dahua Technology 32CH Penta-brid
Dahua Technology

32CH Penta-brid

5MP Value/1080P 1U 2HDDs WizSense Digital Video Recorder

Model XVR5232AN-I3/TEAN 6937552415065

49 specifications
  • OSEmbedded LINUX
  • Weight1.9 kg
  • ColourBlack
  • Maximum video resolution3840 x 2160 pixels
  • Video input channels32 channels
  • Mobile network connectionNo
See all specifications

Overview

OS
Embedded LINUX
Weight
1.9 kg
Colour
Black
Maximum video resolution
3840 x 2160 pixels
Video input channels
32 channels
Mobile network connection
No
Brand
Dahua Technology
Model
XVR5232AN-I3/T
Part number
XVR5232AN-I3/T
EAN / UPC
6937552415065
Also known as
Dahua Technology 32CH Penta-brid 5MP Value/1080P 1U 2HDDs WizSense Digital Video Recorder

Specifications

49 specifications in 10 groups

Performance

Maximum video resolution3840 x 2160 pixels
Audio formats supportedG.711 A-law, G.711 μ-law, PCM
Video compression formatsH.264, H.264+, H.265, H.265+
InternalNo
Video motion detectionYes
Audio system2-way
Bit rate6144 Kbit/s
Dual stream supportYes
Graphical user interface (GUI)Yes
Multi-display modes1, 4, 8, 9, 16, 25, 36
Multi-display supportedYes
Operating system installedEmbedded LINUX
Product colourBlack
CertificationCE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014

Video

Video resolutions1280 x 1024,1280 x 720,1920 x 1080,3840 x 2160

Ports & interfaces

Video input channels32 channels
BNC input ports32
HDMI ports quantity1
VGA (D-Sub) output ports1
USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Line inputs (RCA)1
Line outputs (RCA)1
RS-485 ports1

Network

Mobile network connectionNo
Mobile network generationNot supported
Wi-FiNo
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Supported network protocolsHTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; P2P

Hard drive

Number of HDDs supported2
HDD interfaceSATA
Maximum HDD capacity16 TB

Processor

Built-in processorYes

Power

Power supply typeDC
DC voltage12 V
Power consumption (typical)16 W

Weight & dimensions

Width375 mm
Depth289.6 mm
Height53 mm
Weight1.9 kg

Packaging data

Package width427 mm
Package depth137 mm
Package height356 mm
Package weight3.24 kg

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-10 - 55 °C
Storage temperature (T-T)-20 - 60 °C
