XVR5104HS-4KL-I2 digital video recorder (DVR) Black
Model XVR5104HS-4KL-I2EAN 5706998422255
36 specifications
- OSEmbedded LINUX
- Weight1.1 kg
- ColourBlack
- Maximum video resolution3840 x 2160 pixels
- HDMI ports quantity1
- Ethernet LANYes
Overview
- OS
- Embedded LINUX
- Weight
- 1.1 kg
- Colour
- Black
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI ports quantity
- 1
- Ethernet LAN
- Yes
- Brand
- Dahua Technology
- Category
- Digital Video Recorders (DVR)
- Model
- XVR5104HS-4KL-I2
- Part numbers
- XVR5104HS-4KL-I2, DH-XVR5104HS-4KL-I2
- EAN / UPC
- 5706998422255, 6939554927485
- Also known as
- Dahua Technology XVR5104HS-4KL-I2 digital video recorder (DVR) Black
Specifications
36 specifications in 8 groups
Performance
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Audio formats supported | AAC, G.711 A-law, PCM |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Backup function | Yes |
| Video capturing speed | 30 fps |
| Video motion detection | Yes |
| Analog signal format system | PAL, SECAM |
| Channels quantity | 4 channels |
| Operating system installed | Embedded LINUX |
| PTZ control | Yes |
| Playback resolutions supported | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Product colour | Black |
| Rack capacity | 1U |
| Certification | FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 2 |
| Video in | 1 |
| RS-485 ports | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet interface type | Fast Ethernet |
| Number of users | 128 user(s) |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
Hard drive
| Specification | Value |
|---|---|
| HDD interface | Serial ATA |
| Maximum HDD capacity | 10 TB |
Power
| Specification | Value |
|---|---|
| Power supply type | DC |
| DC voltage | 12 V |
| Power consumption (typical) | 7 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 260 mm |
| Depth | 238 mm |
| Height | 48 mm |
| Weight | 1.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 1.5 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -20 - 70 °C |
