DHT0330026 digital video recorder (DVR)
Model DHT0330026
26 specifications
- Resolution1920 x 1080 pixels
- Storage16 TB
- Video input channels32 channels
- Number of HDDs supported2
- Built-in displayYes
- Audio channels32
Overview
- Resolution
- 1920 x 1080 pixels
- Storage
- 16 TB
- Video input channels
- 32 channels
- Number of HDDs supported
- 2
- Built-in display
- Yes
- Audio channels
- 32
- Brand
- Dahua Technology
- Category
- Digital Video Recorders (DVR)
- Model
- DHT0330026
- Part number
- DHT0330026
- Also known as
- Dahua Technology DHT0330026 digital video recorder (DVR)
Specifications
26 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Video capturing speed | 15 fps |
| Video capturing speed (NTSC) | 15 fps |
| Video capturing speed (PAL) | 15 fps |
| Video loss detection | Yes |
| Video motion detection | Yes |
| Audio streaming | Yes |
| Audio system | 2-way |
| Channels quantity | 32 channels |
| Class | 32CH Penta-brid 1080N/720P 1U 2HDDs WizSense Digital Video Recorder |
| Maximum frame rate | 15 fps |
| Video streaming | Yes |
| Rack capacity | 1U |
Video
| Specification | Value |
|---|---|
| Video resolutions | 1920 x 1080 pixels |
Ports & interfaces
| Specification | Value |
|---|---|
| Video input channels | 32 channels |
| Video in | 32-ch Analog Video Input, Max. 1080N/720p@15fps Encoding Capability, Max. 20-ch IP Video Input (Up to 6MP) |
Hard drive
| Specification | Value |
|---|---|
| Number of HDDs supported | 2 |
| HDD interface | SATA |
| Maximum HDD capacity | 16 TB |
| HDD capacity | 16 TB |
| Supported HDD interfaces | Serial ATA III |
| Media type | Digital |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display resolution | 1920 x 1080 pixels |
| Display frame rate | 15 fps |
Technical details
| Specification | Value |
|---|---|
| Audio channels | 32 |
