QBoat Sunny
Model QBoat SunnyPart no. QBOAT SUNNYEAN 4713213512296
34 specifications
- ProcessorAL-314
- TypeSystem on Module
- Weight490 g
- Processor manufacturerAnnapurna Labs
- Maximum internal memory2 GB
- Wi-FiNo
Overview
- Processor
- AL-314
- Type
- System on Module
- Weight
- 490 g
- Processor manufacturer
- Annapurna Labs
- Maximum internal memory
- 2 GB
- Wi-Fi
- No
- Brand
- QNAP
- Category
- Development Board
- Model
- QBoat Sunny
- Part number
- QBOAT SUNNY
- EAN / UPC
- 4713213512296
- Also known as
- QNAP QBoat Sunny development board AL-314 1.7 MHz
Specifications
34 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Annapurna Labs |
| Processor model | AL-314 |
| Processor frequency | 1.7 MHz |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory | 2 GB |
| Internal memory type | DDR3L |
| Memory bandwidth (max) | 6 GB/s |
| Flash memory | 512 MB |
| Flash memory type | NAND |
| SSD form factor | M.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 2 |
| Audio port type | 3.5mm |
| Ethernet LAN (RJ-45) ports | 3 |
| Number of SATA III connectors | 1 |
| Number of M.2 (M) slots | 2 |
Features
| Specification | Value |
|---|---|
| Form factor | System on Module |
| On/off button | Yes |
| Reset button | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Board dimensions | 126 x 33.5 mm |
| Height | 33.5 mm |
| Weight | 490 g |
| Depth | 126 mm |
| Width | 144 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Other features
| Specification | Value |
|---|---|
| Power consumption (typical) | 13.31 W |
| Power consumption (idle) | 9.49 W |
| LED indicators | SSD, Status, WAN |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 1.05 kg |
