Viewsonic Pro9520WL Standard throw projector 5200 ANSI lumens DLP WXGA (1280x800) White

Viewsonic Pro9520WL Standard throw projector 5200 ANSI lumens DLP WXGA (1280x800) White

Model Pro9520WLPart no. PRO9520WLEAN 766907848014

79 specifications
  • TypeStandard throw projector
  • Weight8.29 kg
  • ColourWhite
  • Projector brightness5200 ANSI lumens
  • Light source typeLamp
  • FocusManual
See all specifications

Overview

Type
Standard throw projector
Weight
8.29 kg
Colour
White
Projector brightness
5200 ANSI lumens
Light source type
Lamp
Focus
Manual
Brand
Viewsonic
Model
Pro9520WL
Part number
PRO9520WL
EAN / UPC
766907848014
Also known as
Viewsonic Pro9520WL Standard throw projector 5200 ANSI lumens DLP WXGA (1280x800) White

Specifications

79 specifications in 17 groups

Projector

Projector brightness5200 ANSI lumens
Projection technologyDLP
Projector native resolutionWXGA (1280x800)
Native aspect ratio16:10
Screen size compatibility525.8 - 8933.2 mm (20.7 - 351.7")
Projection distance1 - 17 m
Number of colours1.073 billion colours
Horizontal scan range15 - 100 kHz
Vertical scan range24 - 120 Hz
Keystone correction, horizontal-30 - 30°
Keystone correction, vertical-30 - 30°

Light source

Light source typeLamp
Service life of light source1500 h
Service life of light source (economic mode)3500 h
Lamp power370 W
Lamps quantity1 lamp(s)

Lens system

FocusManual
Zoom capabilityYes
Zoom typeManual
Optical zoom1.7x
Throw ratio1.32 - 2.24:1
Horizontal lens shift range-10.9 - 10.9%
Vertical lens shift range-12.7 - 23.7%

Video

Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 642, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1152 x 870, 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 960, 1368 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity1
HDMI connector typeFull-size
HDMI version1.4
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portYes
S-Video inputs quantity1
USB 2.0 ports quantity2
Audio (L/R) in1
Serial interface typeRS-232
PC Audio inYes
PC Audio outYes
BNC input ports5
12V triggerYes
Mobile High-Definition Link (MHL)Yes
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

On Screen Display (OSD)Yes
CertificationUL, cUL, FCC, CE, EMC, CB, REACH, SVCH, WEEE, ErP, Mexico NOM/ENERGY, PSB, RCM, CCC

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers2

Design

Product typeStandard throw projector
Market positioningPortable
Product colourWhite
PlacementCeiling
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (standby)0.5 W
Power consumption (max)480 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)10 - 85%

Weight & dimensions

Weight8.29 kg
Width445 mm
Depth147.8 mm
Height325.5 mm
Package width576 mm
Package depth291 mm
Package height436 mm
Package weight12.4 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC, VGA
Quick start guideYes

Technical details

Compliance certificatesRoHS

Other features

RS-232 ports1
