Viewsonic PJD6543W data projector 3000 ANSI lumens DLP WXGA (1280x800) 3D Black

Viewsonic PJD6543W data projector 3000 ANSI lumens DLP WXGA (1280x800) 3D Black

Model PJD6543WEAN 7669076646142

73 specifications
  • Noise32 dB
  • Weight2.1 kg
  • ColourBlack
  • Projector brightness3000 ANSI lumens
  • Light source typeLamp
  • FocusManual
See all specifications

Overview

Noise
32 dB
Weight
2.1 kg
Colour
Black
Projector brightness
3000 ANSI lumens
Light source type
Lamp
Focus
Manual
Brand
Viewsonic
Model
PJD6543W
Part number
PJD6543W
EAN / UPC
7669076646142, 132017770130, 151903596869, 617407473698 +6 more
Also known as
Viewsonic PJD6543W data projector 3000 ANSI lumens DLP WXGA (1280x800) 3D Black

Specifications

73 specifications in 18 groups

Projector

Projector brightness3000 ANSI lumens
Projection technologyDLP
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)15000:1
Native aspect ratio16:10
Supported aspect ratios16:10
Screen size compatibility711.2 - 7620 mm (28 - 300")
Projection distance0.9 - 9.7 m
Keystone correction, vertical-40 - 40°

Light source

Light source typeLamp
Service life of light source4500 h
Service life of light source (economic mode)6000 h
Lamp power190 W

Lens system

FocusManual
Optical zoom1.1x

Video

Analog signal format systemNTSC M, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Full HDNo
HD-ReadyYes
3DYes
3D ReadyYes
Supported graphics resolutions1600 x 1200 (UXGA)
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity1
Component video (YPbPr/YCbCr) in2
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity1
Audio (L/R) in1
Audio (L/R) out1
Serial interface typeRS-232
USB connector typeMini-USB B

Network

Ethernet LANNo
Ethernet LAN (RJ-45) ports0
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level32 dB
Noise level (economic mode)29 dB
HDCPNo
Noise reductionYes

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power2 W

Design

Market positioningPresentation
Product colourBlack
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)240 W
Power consumption (standby)0.5 W
AC input voltage100 - 240 V

Software

Windows operating systems supportedYes
Mac operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Operating altitude0 - 3048 m

Weight & dimensions

Weight2.1 kg
Width268 mm
Depth221 mm
Height84.4 mm
Package width360 mm
Package depth188 mm
Package height325 mm
Package weight3.4 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC, VGA
ManualYes
Quick start guideYes

Technical details

Compliance certificatesRoHS

Other features

RS-232 ports1
