Viewsonic PJ560D 3200 ANSI lumens DLP XGA (1024x768)

Viewsonic PJ560D 3200 ANSI lumens DLP XGA (1024x768)

Model PJ560DPart no. VS11990

33 specifications
  • Noise37 dB
  • Weight2.7 kg
  • Projector brightness3200 ANSI lumens
  • Light source typeLamp
  • FocusManual
  • Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM
See all specifications

Overview

Noise
37 dB
Weight
2.7 kg
Projector brightness
3200 ANSI lumens
Light source type
Lamp
Focus
Manual
Analog signal format system
NTSC, NTSC 4.43, PAL, SECAM
Brand
Viewsonic
Model
PJ560D
Part number
VS11990
Also known as
Viewsonic PJ560D 3200 ANSI lumens DLP XGA (1024x768)

Specifications

33 specifications in 12 groups

Projector

Projector brightness3200 ANSI lumens
Projection technologyDLP
Projector native resolutionXGA (1024x768)
Contrast ratio (typical)2000:1
Screen size compatibility27.2/250
Horizontal scan range31 - 79 kHz
Vertical scan range56 - 85 Hz
Keystone correction, vertical± 40°

Light source

Light source typeLamp
Service life of light source3500 h
Lamp power280 W

Lens system

FocusManual
Throw ratio1.97 - 2.16:1

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM
HD-ReadyYes

Ports & interfaces

VGA (D-Sub) ports quantity2
Component video (YPbPr/YCbCr) in1
S-Video inputs quantity1
USB 2.0 ports quantity1
Serial interface typeRS-232

Features

Noise level37 dB
CertificationUL/cUL, FCC-B, CE, CB, CCC, NOM, C-UL, ICES-003, IRAM, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, RoHS

Multimedia

Number of built-in speakers2
RMS rated power5 W

Design

Market positioningPortable

Power

Power consumption (typical)280 W

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Weight2.7 kg

Other features

Aspect ratio4:3, 16:9
Dimensions (WxDxH)277 x 223 x 109 mm
Power requirements100-240 VAC, 50-60Hz
RS-232 ports1
