Viewsonic PJ513DB data projector 2200 ANSI lumens DLP SVGA (800x600)

Viewsonic PJ513DB data projector 2200 ANSI lumens DLP SVGA (800x600)

Model PJ513DBEAN 766907284317

45 specifications
  • ConnectivityWired
  • Weight2.6 kg
  • Projector brightness2200 ANSI lumens
  • Light source typeLamp
  • FocusManual
  • Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM
See all specifications

Overview

Connectivity
Wired
Weight
2.6 kg
Projector brightness
2200 ANSI lumens
Light source type
Lamp
Focus
Manual
Analog signal format system
NTSC, NTSC 4.43, PAL, SECAM
Brand
Viewsonic
Model
PJ513DB
Part number
PJ513DB
EAN / UPC
766907284317, 766907296518
Also known as
Viewsonic PJ513DB data projector 2200 ANSI lumens DLP SVGA (800x600)

Specifications

45 specifications in 14 groups

Projector

Projector brightness2200 ANSI lumens
Projection technologyDLP
Projector native resolutionSVGA (800x600)
Contrast ratio (typical)2000:1
Screen size compatibility939.8 - 4114.8 mm (37 - 162")
Projection distance1.5 - 6 m
Horizontal scan range30 - 70 kHz
Vertical scan range50 - 87 Hz
Keystone correction, vertical± 25°

Light source

Light source typeLamp
Service life of light source2000 h
Service life of light source (economic mode)3000 h
Lamp power180 W

Lens system

FocusManual

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM
HD-ReadyYes

Ports & interfaces

VGA (D-Sub) ports quantity1
HDMI ports quantity0
Component video (YPbPr/YCbCr) in1
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity0
Audio (L/R) in1
Serial interface typeRS-232
AC (power) inYes

Network

Ethernet LANNo
Ethernet LAN (RJ-45) ports0
Wi-FiNo

Features

CertificationFCC-B, CE, CB, CCC, NOM, C-TICK, ICES 003, GS, GOST-R, HYGIENIC, UKrSEPRO, RoHS

Multimedia

Built-in speaker(s)No

Design

Market positioningPortable

Power

Power consumption (typical)260 W

Operational conditions

Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Weight2.6 kg
Package weight3.8 kg

Packaging content

Remote control includedYes
Cables includedVGA

Other features

Aspect ratio16:9
Connectivity technologyWired
Dimensions (WxDxH)263 x 218 x 108 mm
Power requirements100-240V, 50/60Hz
RS-232 ports1
Non-operating relative humidity (non-condensing)10 - 90%
Weight (imperial)2.59 kg (5.7 lbs)
