PA700WC 4500 ANSI lumens DMD WXGA (1200x800) White
Model PA700WCPart no. 766907026665EAN 766907026665
76 specifications
- Noise34 dB
- Weight2.7 kg
- ColourWhite
- Projector brightness4500 ANSI lumens
- Light source typeLamp
- Focal length range21.85 - 24 mm
Overview
- Noise
- 34 dB
- Weight
- 2.7 kg
- Colour
- White
- Projector brightness
- 4500 ANSI lumens
- Light source type
- Lamp
- Focal length range
- 21.85 - 24 mm
- Brand
- Viewsonic
- Category
- Data Projector
- Model
- PA700WC
- Part number
- 766907026665
- EAN / UPC
- 766907026665
- Also known as
- Viewsonic PA700WC 4500 ANSI lumens DMD WXGA (1200x800) White
Specifications
76 specifications in 16 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4500 ANSI lumens |
| Projection technology | DMD |
| Projector native resolution | WXGA (1200x800) |
| Contrast ratio (typical) | 12000:1 |
| Native aspect ratio | 16:9 |
| Smart projector | No |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Number of colours | 1.07 billion colours |
| Horizontal scan range | 15 - 102 kHz |
| Vertical scan range | 23 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 4000 h |
| Service life of light source (economic mode) | 12000 h |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 21.85 - 24 mm |
| Aperture range (F-F) | 2.41 - 2.53 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Digital zoom | 2x |
| Optical zoom | 1.1x |
| Throw ratio | 1.544 - 1.72 |
| Offset | 112.4% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Supported graphics resolutions | 640 x 480 (VGA), 3840 x 2160 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | No |
| Service port type | USB Type-A |
| USB 2.0 Type-A ports quantity | 2 |
| Headphone outputs | 1 |
| Serial interface type | RS-232 |
| PC in (D-Sub) | Yes |
| DC-in jack | Yes |
| Audio Return Channel (ARC) | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 34 dB |
| Noise level (economic mode) | 25 dB |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, English, Spanish, Finnish, French, Greek, Indonesian, Japanese, Korean, Polish, Russian, Swedish, Thai, Vietnamese |
| Number of OSD languages | 22 |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 3 W |
Design
| Specification | Value |
|---|---|
| Market positioning | Home cinema |
| Product colour | White |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 295 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.7 kg |
| Width | 309 mm |
| Depth | 234 mm |
| Height | 115 mm |
| Package width | 400 mm |
| Package depth | 337 mm |
| Package height | 168 mm |
| Package weight | 3.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | AC |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Image lag time | 33.2 ms |
